Sjw Three-Phase High Accuracy Full-Automatic AC Voltage Stabilizer (SJW-20kVA)

Name: Sjw Three-Phase High Accuracy Full-Automatic AC Voltage Stabilizer (SJW-20kVA)
Brand: all-electronics-online.com
SKU: 723362445
Availability: InStock
Rating: 4.4 (89 reviews)

Price:	US $ 10/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	SJW-20KVA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Input Voltage:	320-430V
Output Voltage:	380V
Rated Capacity:	1.5kVA---45kVA
Efficiency:	90
Current Type:	AC
Phase:	Three Phase
Usage:	Sjw
Frequency:	Low Frequency
Brand:	Powlik

Product Description

SJW Three-Phase High Accuracy Full-Automatic AC Voltage Stabilizer (SJW-20kVA)

Principle & Characteristics
This product is constructed by connecting the three pieces of high accuracy full-automaatic AC voltage stabilizers with Y connection method, has the advantage of: Wide input voltage range, high efficiency, with over(under)voltage, over-current protection function, high regulation accuracy, short adjusting time, same input and output voltage waveform, small volume, less weight.

Scope of Application
It is available in the electric equipments and facilities in housing, factory, school, shop, office, precision instrument for scientific experiment, can long hours circulate.
Main Technical Data
1. Input Voltage Range: 320V-430V or as customer required
2. Output Voltage: 380V+/-4%
3. Frequency: 50/60Hz
4. Regulating time: <1s ( when input voltage varies 10% )
5. Max rated output current: 1.5KVA /2A, 3KVA/4A, 4.5KVA/6A, 6KVA/8A, 9KVA / 12A, 15KVA/20A, 20KVA/ 28A, 30KVA/40A, 45KVA/60A.
6. Ambient temp.: -5º C~+40º C
7. Temperature-rise: < 60º C
8. Relative humidity: Less than 90%
9. Waveform distortion: No additional distortion
10. Efficiency: > 90%
11. Withstand voltage: 1500V/1min

Phase	Capacity (VA)	Overall Size (W×D×L) (mm)	Package size (W×D×L) (mm)	N.W KG
3-phase Movable Type SJW	SJW-1500	485x340x165	560x415x240	14
	SJW-3000	485x340x165	560x415x240	16.5
	SJW-4500	485x340x165	560x415x240	17.5
3-phase Cubicle Type SJW	SJW-6K	285x330x680	410x365x760	29.5
	SJW-9K	320x330x760	410x410x845	40.5
	SJW-15K	355x360x870	440x450x960	50.6
	SJW-20K	510x425x980	510x485x935	81.5
	SJW-30K	510x425x980	605x510x1080	107.5
	SJW-45K	555x450x1170	660x550x1340	138
