Slmv 3p Over Load Protect Breaker Mmcb Moulded Case Circuit Breaker

Name: Slmv 3p Over Load Protect Breaker Mmcb Moulded Case Circuit Breaker
Brand: all-electronics-online.com
SKU: 734648575
Availability: InStock
Rating: 4.8 (20 reviews)

Price:	US $ 3-10/Piece
Trade Terms:	FOB,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,D/P,Money Gram,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	SLMV Breaker
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Mmcb:	Moulded Case Beaker
Structure:	ELCB
Breaking Capacity:	Low Voltage Circuit Breakers
Certification:	CCC
Operation:	Electric Type
Installation:	Fixed
Arc-extinguishing Medium:	Air
Speed:	Normal Type Circuit Breaker

Product Description

Application

SLMV breaker is applied to control the overload, phasebroken, shortcircuit protection and non-frequent start of three phase squirrel-cage asynchronous electromotor in the circuit with max AV690 and 0.16-32A current, and is used as distribution line
Protection and nonfrequent overload conversion, and is also used as the isolator.

Main Technical Specications

Main Technical Speifications

Type	Rated current(A)	Motor output (kW)	Setting range(A)		Order No.	Weight approx. (kg)packing
Type	Rated current(A)	Motor output (kW)	Thermal overload releases	Instantaneous overcurrent releases	Order No.	Weight approx. (kg)packing
SLMV2-80	2.5	0.75	1.6-2.5	30	M07	30 48.5x43x21 27 26
	4	11/1.5	2.5-4	48	M08
	6	2.2	4-6	72	M10
	10	3/4	6-10	120	M14
	16	1.5/7.5	10-16	190	M20
	20	7.5/10	16-20	240	M21
	25	11	20-25	300	M25
	40	18.5	25-40	480	M40
	63	28	40--63	720	M63
	80	32	56-82	960	M80
SLMV2-32	0.16	0.04	0.14-0.15	1.9	M01C	50 46.5x25x17.5 14.5 13.2
	0.25	0.07	0.15-0.25	3.0	M02C
	0.4	0.07/0.12	0.25-4	4.8	M03C
	0.63	0.12/0.18	0.4-0.63	7.2	M04C
	1	0.25	0.63-1	12	M05C
	1.6	0.37/0.55	1-1.6	19	M06C
	2.5	0.75	1.6-2.5	30	M07C
	4.0	1.1/1.5	2.5-4	51	M08C
	6.3	2.2	4-6.3	78	M10C
	10	3/4	6-10	138	M14C
	14	4/6.5	9-14	170	M16C
	18	7/8	13-18	220	M20C
	23	8/10	17-23	320	M21C
	25	9/12	20-25	350	M22C
	32	15	24-32	420	M32C
SLMV2-25	0.16	0.037	0.1-*1.6	1.9	M01	100 48.5x43x21 27 26
	0.25	0.065	0.16-0.25	3	M02
	0.4	0.075/0.12	0.25-0.4	4.8	M03
	0.6	0.1/0.18	0.4-0.6	7.2	M04
	1	0.25	0.6-1	12	M05
	1.6	0.37/0.55	1-1.6	19	M06
	2.5	0.75	1.6-2.5	30	M07
	4	4	2.5-4	18	M08
	6	2.2	4-6	72	M10
	10	3/4	6-10	120	M14
	16	5/7.5	10-16	192	M20
	20	7.5/9	16-20	240	M21
	25	9/11	20-25	300	M22
