Sm Duplex Fiber Optic Patch Cord LC/Upc
| Price: |
US $ 1-1.5/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
50/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
LC/UPC-LC/UPC-DUAL |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Connector Type: |
LC/Upc to LC/Upc |
| Fiber Type: |
G652D,9/125um |
| Fiber Od.: |
3.0mm |
| Jacket Material: |
PVC or Lszh |
| Length: |
3m*2 |
| Operation Temperature: |
-40~+80ºC. |
| Application: |
Communication |
| Type: |
Single-mode Fiber |
| Certification: |
ISO9001 |
| Brand: |
Daytai/ OEM |
| Sheath Material: |
PVC/ Lszh |
| Connection Structure: |
LC/Upc to LC/Upc |
Product Description
1. Description of SM Duplex Fiber Optic Patch Cord LC/UPC
* Optical Fiber Patch Cord
* LC/UPC to LC/UPC connector*2
* G652D,9/125um
* Dual fiber
* OD: 3.0MM
* PVC or LSZH Jacket is optional
* Length:3M*2 (The length of other requirements can be provide)
2. Features of SM Duplex Fiber Optic Patch Cord LC/UPC
* Insertion Loss: APC<0.3dB ,PC<0.2dB., UPC<0.15dB
* Return Loss: SM: PC>45dB, UPC>50dB, APC>60dB.
* MM: >35dB.
* Repeatability: ≤ 0.1dB.
* Exchange: ≤0.2dB.
* Push-pull Performance:≥1000 Cycle.
* Operation Temperature: -40~+80ºC.
3. Product Applications:
* Long Distance OpticalCommunication.
* Optical Testing System.
* LAN and MAN.
* CATV System.
* Digital Communication System.
4. ReliabilityText Condition:
| Item | Text Condition | Text Value |
Optical | Insertion Loss | 1.3um LED Laser | ≤0.2dB |
| Return Loss | 1.3um LED Laser | ≥50dB |
Mechanized | Exchange | Interchangeable Random | <0.2dB |
| Vibration | 5~2000Hz,1.5mm Amplitude | <0.1dB |
| Push-pull | >1000 Cycle | <0.1dB |
Environments | High Temperature Storage | +85ºC For 100h | <0.2dB |
| Low Temperature Storage | -40ºC For 100h | <0.2dB |
| Temperature Storage | -40ºC~+85ºC, 50 Cycles | <0.2dB |
| Relative Humility | +25ºC~+65ºC, 93%R.H, For 100h | <0.2dB |
About Us:
Hangzhou DAYTAI Network Technologies Co., Ltd
Business:
DAYTAI Specialized In Fiber Optic Communication Product, Ethernet & CATV Equipment Production& Provider.
Supply The Whole Range Of Equipment For Fiber Optic Networks And CATV Equipment, Including:
Fiber Optic Cable (GYTA, GYTS, GYXTW, GYTC8S, GYXTC8S, GYTA53, ADSS, OPGW etc...), FTTH
Drop Cable (RFP FTTH Drop Cable, Steel FTTH Drop Cable, etc...), coaxial Cable(RG58, RG59, RG6,
RG6U, RG7, RG11, F15, QR320, QR412, QR500, QR540), 50 Ohm Feeder Cable, LAN Cable
(CAT5e UTP Cable, CAT5e FTP Cable, Alarm Cable)CATV Outdoor Amplifier, CATV House
Amplifier, CATV Splitter, CATV Tap, CATV Attenuator, CATV Filter(High Pass Filter, Low Pass Filter,
Band Reject Filter), Isolator, Wall Outlet, CATV Connector, Satellite Product (IF Amplifier, DiSEqC
Switch, Satellite Finder, Satellite Digital Receiver), Optical Transmitter (1550 & 1310 Nm),
Optical Receiver (outdoor & Indoor, FTTH), EDFA, GEPON, WDM, PLC, Optical Passives
(optical Coupler, Attenuator, Filter, Patch Cord, Pigtail, Adaptor, Optical Closure, Termination Box,
Distribution & Cross Cabinet), Splicing (fusion Splicer & Tool), Measuring Equipment (OTDR,
Optical Light Source, Optical Power Meter, Optical Fiber Identifier, Signal Level Meter), Ethernet
Equipment (media Converter, Switch, Transceiver, Router, SFP, XFP, GBIC Module), Network
Accessories Patch Cord, Plug, PVC Boot, RJ45 Module, Socket, Face Plate, Patch Panel, Cable
Tester & Tool).
Advantage:
1. ----One-stop Electronic Shop Gathers Thousands Of Products From The Best Chinese
Factories As Well As Some Well-known Brands.
2. ----Provide Only The Best Quality Products, With Fast And On Time Delivery At
Competitive Prices, We Stock Most Of The Commonly Used Products.
3. ----Offer Products Of A Consistent Quality. QC Team Monitors The Manufacturing
Process And Inspects All Products Before Shipment.
4. ----Constantly Screen The Chinese Fiber Optic And CATV Equipment Market In A
Search Of The Most Efficient Product Solutions Available To Satisfy Your Individual Needs.
5. ----A Professional Customer Service Team Is Always Ready To Consult You On All The
Issues Related To Our Products.
Major Markets:
The Chinese Mainland, The United States, Canada, Korea, France, Germany, Britain, Turkey,
Ukraine, Italy, Australia, India, The Philippines, South Africa, Indonesia, Mexico, Brazil And Other
Countries.
