Small Batch PCB 6 Layer 2.12mm Thick with Enig Board
| Price: |
US $ 0.71/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC1294R1.3 |
| Surface Finish: |
Immersion Gold |
| Minimum Trace And Space: |
5.5 Mil/6.6 Mil |
| Minimum/Maximum Holes: |
0.4/2.5mm |
| Solder Mask Olor: |
Green |
| Legend Color: |
White |
| Copper Thick: |
1 Oz |
| Board Thick: |
2.12mm |
| Inner Copper Thick: |
1 Oz |
| Via: |
Via Tented |
| Test: |
100% Electrical Test |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Multilayer PCB 6 Layer PCB At 2.12mm Thick Small Batch immersion Gold Applied In CATV
Amplifier
Commodity Introduction
This is a type of FR-4 PCB for the application of CATV Amplifier It's a 6 layer board at 1.6mm
thick. The base laminate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated
per IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels are packed sepa
-rately.
Parameters & Data Sheet| PCB SIZE | 86 x87mm=1PCS |
| BOARD TYPE | |
| Number of Layers | Multilayer PCB,6 Layer |
| Surface Mount Components | YES |
| Through Hole Components | YES |
| LAYER STACKUP | copper ------- 17um(0.5oz)+plate TOP layer |
| Prepreg (2 X 7628) + (2 X 7628HR) 31.2mils |
| copper ------- 35um(1oz) |
| FR-4 0.1mm |
| copper ------- 35um(1oz) |
| Prepreg 1080*2(68%), 5.0mil±10% |
| copper ------- 35um(1oz) |
| FR-4 0.1mm |
| copper ------- 35um(1oz) |
| Prepreg (2 X 7628) + (2 X 7628HR) 31.2mils |
| copper ------- 17um(0.5oz)+plate TOP layer |
| TECHNOLOGY | |
| Minimum Trace and Space: | 5.5mil/6.6mil |
| Minimum / Maximum Holes: | 0.4/2.5mm |
| Number of Different Holes: | 19 |
| Number of Drill Holes: | 5368 |
| Number of Milled Slots: | 0 |
| Number of Internal Cutouts: | 0 |
| Impedance Control | NO |
| BOARD MATERIAL | |
| Glass Epoxy: | FR-4, ITEQ IT-140, TG>135, er<5.4 |
| Final foil external: | 1oz |
| Final foil internal: | 1oz |
| Final height of PCB: | 2.12mm ±10% |
| PLATING AND COATING | |
| Surface Finish | Electroless nickel over Immersion Gold (ENIG)( 2 µ" over 100 µ" nickel) |
| Solder Mask Apply To: | Top and Bottom, 12micon Minimum. |
| Solder Mask Color: | Green, PSR-2000GT600D, Taiyo supplied. |
| Solder Mask Type: | LPSM |
| CONTOUR/CUTTING | Routing |
| MARKING | |
| Side of Component Legend | TOP |
| Colour of Component Legend | White, IJR-4000 MW300, Taiyo Supplied. |
| Manufacturer Name or Logo: | Marked on the board in a conductor and
leged FREE AREA |
| VIA | Plated Through Hole(PTH), via tented. |
| FLAMIBILITY RATING | UL 94-V0 Approval MIN. |
| DIMENSION TOLERANCE | |
| Outline dimension: | 0.0059" (0.15mm) |
| Board plating: | 0.0030" (0.076mm) |
| Drill tolerance: | 0.002" (0.05mm) |
| TEST | 100% Electrical Test prior shipment |
| APPLICATION: | CATV amplifier, Wireless Adaptor
Portable Speaker System
Satellite Tracking
USB Router
Voip Router |
| TYPE OF ARTWORK TO BE SUPPLIED | email file, Gerber RS-274-X, PCBDOC etc |
| SERVICE AREA | Worldwide, Globally. |
PCB Classification --- Multilayer PCB
In order to increase the area that can be wired, multilayer board uses more single or double sided
wiring board.
PCB using a double side board as inner layer and two pieces of single layer as the outer layer or
two double-sided printed circuit board as the inner layer and two pieces of single layer as the outer
layer, through the insulation and bonding materials to press each layer together, and the conductive
pattern are as per design requirements for interconnection becomes the 4 layers of printed circuit
board, 6 layers of printed circuit board, also known as multilayer printed circuit board.
The number of layers of the board does not represent a separate layer of wiring. In particular, the
air layer will be joined to control the thickness of the board. Usually the number of layers is even,
and contains the outermost 2 layers. Most of the host mainboard is 4 to 8 layers of structure, but
the theory can be technically nearly 100 layers of PCB boards. Large supercomputers use quite
a lot of layers of mainframe board, but because this kind of computer can be replaced with a lot
of ordinary computer clusters, super multilayer board has gradually not been used. Because all
of the layers in the PCB are closely combined, it is generally not easy to see the actual number,
but if you look carefully at the motherboard, you can also see it.
PCB can be also classified by its softness. There're rigid PCB, flexible PCB and Rigid-flex PCB.
Metal core PCB and high frequency PCB are classified by its material.
