Small Outline Bridge Rectifier

Name: Small Outline Bridge Rectifier
Brand: all-electronics-online.com
SKU: 709123432
Availability: InStock
Rating: 4.4 (62 reviews)

Price:	US $ 0.1-3/Piece
Trade Terms:	FOB
Min Order:	12/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	KBPC
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Vrrm:	100-1200V
Irrm:	5-10mA
Vfm:	1.3-1.5V
Ifm:	8-125A
Manufacturing Technology:	Discrete Device
Material:	Element Semiconductor
Type:	Intrinsic Semiconductor
Package:	Standard Export Packing
Application:	Eliminator Supply, Industry Automatic Control
Model:	Kbpc

Product Description

Features
ID@TC55° C: 5A~300A
Voltage: 100V~1600V
Small general outline
Vacuum weld techinics
GPP CELL diode chip
Good power/volume
High temp. Conduct packing

Typical Applications
Rectification power
Automate control
Numerical control machinery

	Single-phase Bridge Rectifier										Three-phase Bridge Rectifier
Part No.	KBPC,BR,GBPC,MDA,QL										SKBPC, SQL
VRRM(V)	100-1200										100-1200
Id@TC=55°C(A)	15	25	35	40	50	60	100	150	200	250	15	25	35	40	50	60	100	150	200	250	300
IRRM(mA)	≤5	≤5	≤5	≤5	≤5	≤7	≤7	≤10	≤10	≤10	≤5	≤5	≤5	≤5	≤5	≤7	≤7	≤10	≤10	≤10	≤10
IFM(A)	8	12	18	20	25	30	50	75	100	125	5	8	12	14	17	20	35	50	70	85	100
VFM(V)	1.3	1.3	1.3	1.3	1.3	1.4	1.4	1.5	1.5	1.5	1.3	1.3	1.3	1.3	1.3	1.4	1.4	1.5	1.5	1.5	1.5
IFSM(A)	300	400	400	500	500	600	1000	2000	2000	2500	300	400	400	500	500	600	1000	2000	2000	2500	2500
Viso(V)	2500										2500
Tj(°C)	-55-+125										-55-+125
Wt(g)	25			35, 48		315		1200			32			55		340		1300
Outline	BR1, BR3			BR2, BR3, BR5		BR6		BR7			BR4			BR5		BR6		BR7

China Shangjing Rectifier Co., Ltd. Was co-founded by China DELIXI Group, Shanghai Rectifier Co., Ltd. And Jingtai Electric Co., Ltd. In 1999. As one of the most professional manufacturers of power semiconductors and silicon rectifying whole set equipments, as well as the manufacturer for timer switch ( programmable timer switch, digital timer switch mechanical timer switch ) and circuit breaker ( mini circuit breaker, DPN miniatire circuit breaker, DPNL residual current circuit breaker etc) our company has been devoted to provide the high quality electronicsr products for our customers all over the world.

Shangjing Rectifier Co., Ltd. is located in Liushi Town which is well known as the "Capital of Electric City" in China. We are very close to the Wenzhou Airport and the deep-water sea port, which makes it very easy for us to reach our customers from the whole world.

Our company has been certified by China Industrial Department and we have got CE certificate. Furthermore, our products are compliant to the latest RoHS directions.

We have brought advanced technologies and equipment from abroad and kept improving our management and products quality. We stick the spirit of "Chasing for high quality and Servicing our clients with all our heart and credibility", we have gained a lot of honors like "AAA class China quality & credibility company", "member of China Electric Industry Association", etc. We have been exporting our products to Europe, South and North America, Middle East, Africa and earned a lot of good feedback.

We hope our high quality products and service will be bringing successful future to all our customers.
