Snat 3 Phase 5kw 10kw 20kw Power Frequency Solar Inverter for Home Solar System

Name: Snat 3 Phase 5kw 10kw 20kw Power Frequency Solar Inverter for Home Solar System
Brand: all-electronics-online.com
SKU: 806912025
Availability: InStock
Rating: 4.8 (95 reviews)

Price:	US $ 1530-1550/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	TP512
Weight:	950kg
Input Voltage:	192VDC/220VDC/240VDC/384VDC
Output Voltage:	220VAC/380VAC
Output Frequency:	50Hz/60Hz
Output Current:	Load
Efficiency:	>95%
Company:	Manufacturer&Trading
OEM/ODM:	Accept
Application:	Industrial,Commerical,Widely
Warranty:	12 Months

Product Description

SNAT 3 Phase 5kw 10kw 20kw Power Frequency Solar Inverter for Home Solar System

Product Description

Efficient IGBT (insulated gate bipolar transistor) inversion technology good high-speed switching feature
Intelligent battery fault detection: measurement of single parameters, display of the measurement results on the LCD and immediate alarming
Greater loading capacity: suitability for industrial applications such as machine tools and wire cutters.
Management function big LCD, visualized display of operation statuses through flow charts
Advanced operation mode ,Frequency tracking, phase-locking voltage stabilization

Technology Paremeter

Model-SNTP	10KW	20KW	30KW	40KW	60KW	80KW	100KW	150KW	200KW
Rated capacity	10kW	20kW	30kW	40kW	60kW	80kW	100kW	150kW	200kW
Operation mode	PWM (pulse width modulation)based on DSP accurate control technology and double built-in MCUs complete isolation of the output power supply
and principle
AC input phase number	Three-phase + N+G
AC input voltage	220/380V AC ±20%
AC input frequency	50/60Hz ±5%
DC voltage	192/220/240/384V DC(16to 32 pieces of 12V batteries)
Floating battery	13.6V of each batterybattery quantity(13.6V16 batteries=217.6)
Cut-off voltage	10.8V of each batterybattery quantity (10.8V16 batteries=172.8V)
Phase number	three-phase +N+G
AC output voltage	220/380V AC± 1% (steady load)
AC output frequency	50/60Hz ± 5% (mains supply)50Hz±0.01%
Efficiency	≥95% (load:100%)
output waveform	sine wave
THD	linear load: <3%, non-linear load: <5%
Dynamic load voltage transient	<±5% (jump from 0 to 100%)
Instant recovery time	<10ms
time of switching between	3-5S
the battery and the mains supply
Unbalanced voltage	<±3% <±1%(balanced load voltage)\|
Overload capacity	120%, 20S, >150%, 100ms
Operation efficiency	≥95% (load: 100%)
Computer communication interface	RS232/RS485 (SNMP remote monitoring network adapter)
Operating temperature	-10-40°C
Relative humidity	0-90% (no condensation)
Noise	40-50dB				50-60dB			60-70dB

Shipping & Payment

Company Information

Foshan SNAT Energy Electrical Technology Co. Ltd is established in 2004. As a world's leading supplier for solutions for electric energy and new energy, SNAT has powerful strength and is engaged in field of solar inverters, solar inverters with built-in solar controller, solar controllers, UPS, which are used for household, telecommunication, electricity, infrastructure and industrial markets. At the same time, our company is concurrently engaged in solar panels, batteries for solar power system. All products purchased by our company have our warranty commitment, parts will be shipped for free during warranty period. We have professional technical team and are focus on customers' demands, continuous innovation, and establish good cooperation with more and more clients.

Certifications

Advantages
A. More than 10 years technical experience and advanced equipment
Our solar products are selling to all over the world, such as North America, south America,Eastern Europe, Southest Asia ,Africa and Mid-East,etc…
B. Quality Certification
80% electronic components are imported,to make sure the products with high quality and reliable excellent performance.
All of our products have CE certification, ISO9001:2008.
C. OEM & ODM
OEM & ODM are available which can meet your any request with our professional engineering team.
D. Quality Service
Any inquiry replied within 12 hours
Any problem resolved within 24 hours
With 12 months warranty
E. As a leading manufacturer,the price of our products is competitive.

Contact us

A Professional Manufacturer Specialized in field of Solar power system

Foshan SNAT Energy Electrical Technology Co. Ltd is a professional manufacturer specialized in the field of solar inverters, solar inverters with controllers built-in, solar controllers, UPS which are used for household, telecom, electricity, infrastructure and industrial markets.

At the same time, our company is concurrently engaged in solar panels, batteries for solar power system. All products purchased by our company have our wanrranty commitment, parts will be shipped for free during wanrranty period.

Company information

Foshan SNAT Energy Electrical Technology Co. Ltd is established in 2004. Our company's predecessor is a trading company and engaged in UPS since 1998 and develop solar inverter since 2004. We are haveing professional technical team and focus on customers' demands, continuous innovation, and establish good cooperation with more and more clients. The leading-edge technology has become a competitive advantage for our customers and business.

Corporate development prospect

Foshan SNAT Energy Electrical Technology Co. Ltd is becoming a strong brand step by step depending on high quality and strict self-demanding. We have won a good reputation among clients. Nowadays, we have prepared well to develop much more wide international market. We sincerely wish to corporate with more and more international traders to vreat a better future!
