| Prod Model: |
GEL 24AH-230AH /12VDC |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Lead-Acid Batteries |
| Usage: |
Electric Power |
| Nominal Voltage: |
12V |
| Discharge Rate: |
Low Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
Soalr Battery Gel (24AH-230AH /12VDC)Key features:1. The primary material is gas silicon dioxide from Import.
2. Fully sealed: With cover and pole double seal design to prevent leakage of electrolysis, and the reliability of safe-vale prevent oxygen and dust from outside enter into the battery.
3. Free maintenance: With the performance of water reproduce and high sealed reaction efficiency, it no needs any compensation of and water during ues.
4. Safety: Without acid leaked, reliable gas pressure venting system and equipped with anti-explosion device, which make the battery safer during use.
5. Long cycle life: Anti-erosion pb-ca multi-alloy, ABS plastic materical and high sealed reaction efficiency assurethe resden batttery's service life.
6. Temperature adaptability: The battery can be used safely during -25-50degree.
7. Convenient and safety: The battery has charged with load befor leaving the factory, without free electrolysis, it allowed to be placed breadthways and transported by sea and railway as nonhazardous material.
8. Economical: With high perforamce, long service life and lowest maintenance cost to offer consumers the most economical procucts.
Application:1. Solar / wind energy system
2. Communication system
3. Broadband
4. UPS
5. Power Tools
6. Cable TV
7. Alarm system
8. Emergency power system
9. Control equipment
10. Photovoltaic
11. Electric Powered Vehicles
12. Marine equipment
13. Vacuum Cleaners
14. Golf Cars and Buggies
15. Electric Wheel Chairs
Product Show:
Technical Specifications | BATTERY MODEL | Voltage | Capacity | Resistance | Charge Voltage (VDC) | Charge Current | Product Size (MM) | Product weight | Terminal type |
| (VDC) | (Ah) | (m∪) | Equalization and Cycle | Float | Maximum Amp | L | W | H | T/H | KG |
| GEL24-12 | 12 | 24 | ≤8.3 | 14.4-15 | 13.65 | 6Amp | 166 | 125 | 175 | 182 | 8.50 | L/O |
| GEL38-12 | 12 | 38 | ≤7.3 | 14.4-15 | 13.65 | 9.5Amp | 197 | 165 | 170 | 182 | 13.80 | L/O |
| GEL65-12 | 12 | 65 | ≤6.1 | 14.4-15 | 13.65 | 16.25Amp | 350 | 167 | 178 | 178 | 21.00 | L/O |
| GEL100-12 D | 12 | 100 | ≤5 | 14.4-15 | 13.65 | 25Amp | 330 | 173 | 220 | 240 | 26.00 | L/O |
| GEL100-12 M | 12 | 100 | ≤4.4 | 14.4-15 | 13.65 | 25Amp | 406 | 174 | 238 | 238 | 29.00 | L/O |
| GEL120-12 | 12 | 120 | ≤4 | 14.4-15 | 13.65 | 25Amp | 406 | 174 | 238 | 238 | 36.00 | L/O |
| GEL150-12 | 12 | 150 | ≤3.5 | 14.4-15 | 13.65 | 35Amp | 484 | 171 | 241 | 241 | 45.00 | L/O |
| GEL200-12 | 12 | 200 | ≤3.4 | 14.4-15 | 13.65 | 50Amp | 520 | 240 | 224 | 244 | 63.00 | L/O |
| GEL230-12 | 12 | 230 | ≤1 | 14.4-15 | 13.65 | 55Amp | 520 | 240 | 224 | 244 | 63.00 | L/O |
Note : 1.10 year Service life,ABS shell.
2.the rate capaticy (10 rate hour)is the average tested by several times at 25ºC
3.the total height of battery includes the terminal. 4."L" terminaldenotes quardrate terminal and postifix "o" terminal denotes cylindrcal terminal.
5.it is to be noted that all these parameters are subject to change without notice. |
|
|
|
|
|
