Stamp Holes PCB 8 Layer Immersion Gold Circuit Board
| Price: |
US $ 0.86/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-165-V1.65 |
| Final Foil External: |
1 Oz |
| Final Height Of PCB: |
1.6mm |
| Surface Finish: |
Immersion Gold |
| Impedance Control: |
Single Trace, 4 Mil, 65 Ohm |
| Impedance Control.: |
Differential Pairs, 4.5/8mil, 100 Ohm |
| Solder Mask Color: |
Green, Psr-2000gt600d, Taiyo Supplied. |
| Colour Of Component Legend: |
White, Ijr-4000 MW300, Taiyo Supplied. |
| Minimum Trace And Space: |
4.5 Mil/4.5 Mil |
| Minimum / Maximum Holes: |
0.3/6.5mm |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Impedance controlled Multilayer PCB Differential Pairs Impedance Immersion Gold In PLC
Program
Commodity IntroductionThis is a type of FR-4 PCB for the application of PLC Program. It's an 8 layer board at 1.6mm
thick.The base laminate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated
per IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels are packed
separately.
Parameters & Data Sheet| PCB SIZE | 215 x 212mm=1PCS |
| BOARD TYPE | |
| Number of Layers | Multilayer PCB, 8 layer PCB |
| Surface Mount Components | YES |
| Through Hole Components | YES |
| LAYER STACKUP | copper ------- 18 um(0.5 oz)+plate TOP layer |
| Prepreg 7628 0.195mm |
| copper ------- 35 um(1 oz) MidLayer 1 |
| FR-4 0.2mm |
| copper ------- 35 um(1 oz) MidLayer 2 |
| Prepreg 7628 0.195mm |
| copper ------- 35 um(1 oz) MidLayer 3 |
| FR-4 0.2mm |
| copper ------- 35 um(1 oz) MidLayer 4 |
| Prepreg 7628 0.195mm |
| copper ------- 35 um(1 oz) MidLayer 5 |
| FR-4 0.2mm |
| copper ------- 35 um(1 oz) MidLayer 6 |
| Prepreg 7628 0.195mm |
| copper ------- 18 um(0.5 oz)+plate BOT Layer |
| TECHNOLOGY | |
| Minimum Trace and Space: | 4.5 mil/4.5 mil |
| Minimum / Maximum Holes: | 0.3/6.5mm |
| Number of Different Holes: | 23 |
| Number of Drill Holes: | 3515 |
| Number of Milled Slots: | 3 |
| Number of Internal Cutouts: | 0 |
| Impedance Control: | Single trace impedance control, L3-L4-L7-L8, 4mil, 65 ohm+/-10%, Differential pairs impedance
control, L1-L3-L4-L7-L8 4.5/8mil, 100 ohm +/-10% |
| Number of Gold finger: | 0 |
| BOARD MATERIAL | |
| Glass Epoxy: | FR-4 TG170ºC, er<5.4.IT-180, ITEQ Supplied |
| Final foil external: | 1 oz |
| Final foil internal: | 1 oz |
| Final height of PCB: | 1.6mm ±0.16 |
| PLATING AND COATING | |
| Surface Finish | Immersion gold (25.1% ) 0.05 µm over 3 µm nickel |
| Solder Mask Apply To: | TOP and Bottom, 12micron Minimum |
| Solder Mask Color: | Green, PSR-2000GT600D, Taiyo Supplied. |
| Solder Mask Type: | LPSM |
| CONTOUR/CUTTING | Routing, stamp holes. |
| MARKING | |
| Side of Component Legend | TOP and Bottom. |
| Colour of Component Legend | White, IJR-4000 MW300, Taiyo Supplied. |
| Manufacturer Name or Logo: | Marked on the board in a conductor and leged FREE AREA |
| VIA | plated through hole(PTH), minimum size 0.3mm. |
| FLAMIBILITY RATING | UL 94-V0 Approval MIN. |
| DIMENSION TOLERANCE | |
| Outline dimension: | 0.0059" (0.15mm) |
| Board plating: | 0.0030" (0.076mm) |
| Drill tolerance: | 0.002" (0.05mm) |
| TEST | 100% Electrical Test prior shipment |
| APPLICATION: | PLC Program
Honeywell Access Control
Car GPS Tracking
Auto Tracking
Door Access System, Neon Power Supply |
TYPE OF ARTWORK
TO BE SUPPLIED | email file, Gerber RS-274-X, PCBDOC etc |
| SERVICE AREA | Worldwide, Globally. |
