SVC-3000va Single-Phae High Accuracy Full-Automatic AC Voltage Stabilizer

Prod Model:	SVC-3000VA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Input Voltage:	160-250V
Output Voltage:	220V/110V
Capacity:	0.5kVA---60kVA
Efficiency:	90%
Current Type:	AC
Phase:	Single Phase
Usage:	SVC
Frequency:	Low Frequency
Brand:	Powlik

Product Description

SVC-3000va Single-Phae High Accuracy Full-Automatic AC Voltage Stabilizer

1) Principle & Characteristics
It adopt linear integrated circuit to form the control system, drive the contact voltage regulator to regulate automatically by controlling the servo motor, it is provided with delay, over-voltage, under-voltage and over-current protection function which ensure the voltage stabilizer can supply safely; It has the advantage of high efficiency, same input and output voltage waveform, stable output voltage, work continuously and so on.

2) Scope of Application
It is available in the electric equipments and facilities in housing, factory, school, shop, office, precision instrument for scientific experiment. And also is suitable for office equipment, test instrument, communication system, industrial equipment, armarium, domestic electric appliance and so on.

3) Main Advantage
Excellent output voltage waveform, stable regulating process, no lost electricity phenomenon;
High accuracy of output voltage, generally it is fixed in 220± 3% when leave the factory, wide input voltage range, strong load adaptability; With satisfiable load property. It has(under-voltage), over-voltage and over-current protection function; It can cutoff the power supply automatically to ensure the safety of the consumer when the output voltage is over-high or the input is over-current; It adopted high breaking capacity mini circuit breaker with the over-current protection function when it is over load or short-circuit; It use high property carbon brush which prolong the service life of the voltage stabilizers

4) Main Technical Data
1. Input Voltage Range: Single phase 160-250V
Three phase 277-430V Or as per customer required
2. Output Voltage: Single phase 220V and 110V
Three phase 380V phase to phase 220V
3. Regulation Accuracy: 220V+/-3% and 110V+/-6%
4. Frequency: 50Hz/60Hz
5. Regulation speed: < 1s ( when input voltage varies 10%)
6. Efficency: >90%
7. Under-voltage protection: 184V+/-4V ( set according to user requirement, normally not set )
8. Over-voltage protection: 246V+/-4V
9. Temperature-rise: <60º C (under full-load condition )
10. Ambient temp, relative humidity: -5º C~+40º C less than 90%
11. Withstand voltage: 1500V/1min
12. Max rated output current: 0.5KVA/2A, 1KVA/4A, 1.5KVA/6A, 2KVA/8A, 3KVA/12A, 5KVA/20A, 10KVA/40A, 15KVA/60A, 20KVA/80A.

Phase	Type (kVA)	Size (D×W×H) (mm)	Packing Size (D×W×H) (mm)	Pcs/ctn		Phase	Type (kVA)	Size (D×W×H) (mm)	Packing Size (D×W×H) (mm)	Pcs/ctn
1 Phase (table type)	SVC-0.5	190×180×130	250×440×350	4		1 phase (Stand type)	SVC-5	300×240×430	310×290×480	1
	SVC-1	220×210×160	280×500×400	4			SVC-8	300×250×450	400×370×560	1
	SVC-1.5	220×210×160	280×500×400	4			SVC-10	300×250×450	400×370×560	1
	SVC-2	270×240×200	340×300×500	2			SVC-15	410×330×650	520×450×760	1
	SVC-3	300×220×250	620×380×350	2			SVC-20	410×330×650	520×450×760	1
	SVC-5	470×240×190	540×320×270	1			SVC-30	430×430×1020	660×560×1120	1
	SVC-8	580×270×240	690×400×370	1			SVC-45	530×430×1020	660×560×1120	1
	SVC-10	580×270×240	690×400×370	1			SVC-60	790×430×1360	900×650×140	1
3 phase	SVC-1.5	400×360×170	520×480×280	1		3 phase	SVC-20	430×510×910	640×550×1060	1
	SVC-3	420×380×190	540×500×310	1			SVC-30	430×510×910	640×550×1060	1
	SVC-4.5	420×380×190	540×500×310	1			SVC-45	650×130×950	780×550×1100	1
	SVC-6	370×280×680	480×400×780	1			SVC-60	650×430×950	780×5500×1100	1
	SVC-9	350×330×780	480×450×900	1
	SVC-15	430×380×730	550×510×900	1
