| Prod Model: |
S-120-12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
S-120-12 |
| Output Type: |
Single |
| Warranty: |
1 Year |
| Output Power: |
101 - 200W |
| Input Voltage: |
110-220V |
| Connection Mode: |
Parallel Switching Power Supply |
| Starting Mode: |
Separate-excited Switching Power Supply |
| Voltage Regulating Mode: |
Frequency Modulation Type |
| Power Supplying System: |
Terminal Power Distribution Equipment |
| Certification: |
CE |
Product Description
Protections: Short circuit/ Overload
? Cooling by free air convection
? 100% full load burn-in test
? Low cost, high reliability
? 1 year warranty |
case::901 159X97X38mm
AC input voltage range ........... 85~264VAC; 120~370VDC
AC inrush current ................... Cold start, 20A at 115VAC, 40A at 230VAC
DC adjustment range ............. 10% rated output voltage
Overload protection ............... 105%~150% hiccup mode, auto-recovery
Over voltage protection ......... 115%~135% rated output voltage
Setup, rise, hold up time ........ 300ms, 50ms, 90ms at full load and 230VAC
Withstand voltage .................. I/P-O/P:3.0KVAC, I/P-FG:1.5KVAC, 1 minute
Working temperature ............. 0~45OC@100%, -10OC@80%, 60OC@60% load
Safety standards ................... UL1012, UL60950-1, TUV EN60950-1 approved
EMC standards ..................... EN55022 class B, EN61000-3-2,3 EN61000-4-2,3,4,5,6,8,11, ENV50204
Connection ............................ 5P/ 9.5mm pitch terminal block
Packing ................................. 0.51 kg ; 24pcs / 13.1 kg / 0.70CUFT
120W Single Output Switching Power Supply,
Certificate: CE
Open frame switching power supplier, power supplier
120W Single Output Switching Power Supply
Certificate: CE
Switching Power Supply, AC/DC adapter, power supply efficiency, high voltage power supply, power switching, change power supply, variable power supply, open frame switching power supplier,
120W Single Output Switching Power Supply
AC input range selectable by switch
Protections: Short circuit/ Overload
Cooling by free air convection
100% full load burn-in test
Low cost, high reliability
1 year warranty
Case: : 902 199X98X38mm
AC input voltage range...85~132VAC / 180~264VAC selectable by switch
AC inrush current...Cold start, 30A at 115VAC, 60A at 230VAC
DC adjustment range...10% rated output voltage
Overload protection...105%~150% shut off, AC recycle to re-start (S-100-7.5: 150%~200%)
Setup, rise, hold up time...200ms, 80ms, 20ms at full load and 230VAC
Withstand voltage...I/P-O/P: 1.5KVAC, I/P-FG: 1.5KVAC, 1 minute
Working temperature...-10~60OC (refer to output derating curve)
Safety standards...Design refer to UL1012
EMC standards...Design refer to FCC part 15 J
Connection...7P / 9.5mm pitch terminal block
Packing...0.62kg; 20PCS / 13.6kg / 0.8CUFT
2000 Pairs Sells per Month
5 pairs MOQ
48-72 hours delivery after received money
