Bicheng Enterprise Limited >> Taconic Tla-35 1.524mm Circuit Board Carbon Ink V-Groove

Taconic Tla-35 1.524mm Circuit Board Carbon Ink V-Groove

Taconic Tla-35 1.524mm Circuit Board Carbon Ink V-Groove
Price: US $ 1.02/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union
Prod Model: BIC-680-V6.80
Final Foil External: 2.0oz
Final Height Of PCB: 0.8mm
Surface Finish: Immersion Gold
Solder Mask Color: No Required
Colour Of Component Legend: No Required
Minimum Trace And Space: 13mil/15mil
Minimum/Maximum Holes: 0.3/3.21mm
Test: 100% Electrical Test Prior Shipment
Via: Via Open
Board Plating: 0.0030"
Type: Rigid Circuit Board
Flame Retardant Properties: V0
Material: Hydrocarbon/Woven Glass
Insulation Materials: Glass Reinforced Hydrocarbon
Dielectric: RO4350b and RO4450b

Product Description

Company Profile
Bicheng Enterprise Limited can help you with following printed circuit boards.

Various kinds of PCB products


  1. Double sided PCB
  2. Multilayer PCB up to 32 layers
  3. FR-4 PCB (Tg130, Tg170)
  4. High frequency PCB (RO4350B, RO4003C)
  5. Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
  6. Flexible PCB

Multiple technology on PCB

  1. Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
  2. Impedance controlled PCB
  3. Heavy copper PCB
  4. Hybrid material PCB

Many discount policies for new customers

  1. SMT stencil foil, free of charge
  2. Prototype shipping cost, free of charge
  3. Prototype test, free of charge
  4. PCB panelization, free of charge

High quality PCB services

  1. Prototype PCB and production PCB
  2. Quick turn-around prototypes
  3. Door to door logistic service
  4. Hassle-free, one-to-one service

High Frequency PCB


Flexible Printed Circuit


Metal Core PCB


PCB Board



Technology Information

Printed Circuit Board Capability
ParameterValue
Layer Counts 1-32
Substrate MaterialFR-4(including High Tg 170, High CTI>600V);
Aluminum based; RO4350B, RO4003C;
Polyimide, 94HB and FR-1 (upon request)
Maximum SizeFlying test: 900*600mm,
Fixture test 460*380mm,
No test 1100*600mm
Board Outline Tolerance±0.0059" (0.15mm)
PCB Thickness0.0157" - 0.3937" (0.40mm--10.00mm)
Thickness Tolerance(T≥0.8mm)±8%
Thickness Tolerance(t<0.8mm)±10%
Insulation Layer Thickness0.00295" - 0.1969" (0.075mm--5.00mm)
Minimum Track0.003" (0.075mm)
Minimum Space0.003" (0.075mm)
Outer Copper Thickness35µm--420µm (1oz-12oz)
Inner Copper Thickness17µm--420µm (0.5oz - 12oz)
Drill Hole(Mechanical)0.0059" - 0.25" (0.15mm--6.35mm)
Finished Hole(Mechanical)0.0039"-0.248" (0.10mm--6.30mm)
DiameterTolerance(Mechanical)0.00295" (0.075mm)
Registration (Mechanical)0.00197" (0.05mm)
Aspect Ratio12:1
Solder Mask TypeLPI
Min Soldermask Bridge0.00315" (0.08mm)
Min Soldermask Clearance0.00197" (0.05mm)
Plug via Diameter0.0098" - 0.0236" (0.25mm--0.60mm)
Impedance Control Tolerance±10%
Surface FinishHASL,HASL LF,ENIG,Imm Tin,
Imm Ag, OSP, Gold Finger

Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.

The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.

Different plant scale to suit for your requirements

16000 square meter factory building

30000 square meter month capability

8000 types of PCB per month

ISO9001, ISO14001, TS16949, UL Certified

We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.

A) Various kinds of PCB products

Double sided PCB

Multilayer PCB up to 32 layers

FR-4 PCB (Tg130, Tg170)

High frequency PCB (RO4350B, RO4003C)

Aluminum PCB (1W/MK, 2W/MK, 3W/MK)

Flexible PCB

HDI PCB Board

B) Multiple PCB technology to meet the market demands

Blind via PCB, Via in pad PCB, Fine pitch BGA PCB

Impedance controlled PCB

Heavy copper PCB

Hybrid material PCB

C) Many discount policies for new customers

SMT stencil foil, free of charge

Prototype shipping cost, free of charge

Prototype test, free of charge

PCB panelization, free of charge

D) High quality PCB services

Engineering design prevents problems from occurring in pre-production.

Meet your PCB needs from prototype to mass volume production.

Eligible products rate of first production: >95%

Delivery on time: >98%, door to door shipment service

Customer complaint rate: <1%

Choose BichengPCB means you choose hassle free.
