Taconic Tla-6 0.94mm Soft Gold PCB Circuit Board Prototype PCB
| Price: |
US $ 1/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-607-V6.07 |
| Outer Copper Thick: |
35 Um (1 Oz) |
| Inner Copper Thick: |
35 Um (1 Oz) |
| Board Thickness: |
0.25mm |
| Coverlay Colour: |
Black |
| Stiffener Thickness: |
1.0mm / 0.2mm |
| Stiffener Material: |
Fr-4 / Stainless Steel |
| Surface Finish: |
Immersion Gold |
| Color Of Silkscreen: |
White |
| RoHS Required: |
Yes |
| Test: |
100% Electrical Test |
| Structure: |
Multilayer FPC |
| Material: |
Polyimide |
| Combination Mode: |
Adhesive Flexible Plate |
| Conductive Adhesive: |
Conductive Silver Paste |
| Application: |
Intercom System |
| Insulation Materials: |
Polyimide |
| Brand: |
Bicheng |
Product Description
Company Profile
Bicheng Enterprise Limited offers single sided / double sided and multilayer circuit boards. We
have been serving PCB electronics industry in Shenzhen, China since 2003.
Our advantages
* Your satisfied source to buy printed circuit boards (PCBs)
* All PCBs are 100% tested (flying probe or fixture test)
* Free panelizing
* Special price for partners
* On time delivery
* No minimum order quantity
* Worldwide shipping, door to door service
Our products
* PCB Prototypes and PCB Production
* Rigid PCB Fabrication
* Flexible PCB (FPC)
* PCB up to 32 layers
* RoHS complaint, Lead free PCBs
* Material: FR-4, High Tg (Tg170, Tg180), RO4350B, RO4003C, Polyimide
* Controlled Impedance
* Surface finish: HASL, HASL lead free, Immersion tin, Immersion silver, Immersion gold, gold
finger
* Blind vias
* 3 days to 4 weeks lead time
Printed Circuit Board
High Frequency PCB
Aluminum PCB
Flexible PCB
Design For Manufacture Serial
NO. | Procedure | Item | Manufacturing capability |
Large volume
(S<100 m²) | Middle volume
(S<10 m²) | Prototype
(S<1m²) |
|
| 84 | Special tolerance | Board thickness
of flying probe test | 0.6-4.0mm |
| 85 | Panel size of
flying probe test | Size≤900X600mm,
Small size can be
compensated through
manufacturing procedure |
| 86 | Panel size of
fixture test method | Size≤460X380mm,
Small size can be
compensated through
manufacturing procedure |
| 87 | Board thickness of
fixture test method | 0.4-6.0mm |
| 88 | Tolerance of
press-fit hole | ±2mil |
| 89 | Tolerance of NPTH | ±2mil |
| 90 | Tolerance of
PCB thickness | 1.0mm≥PCB thickness,
Tolerance ±0.1mm;
1.0mm≤PCB thickness,
Tolerance ±10% |
| 91 | Tolerance of depth
of countersunk hole | ±0.2mm |
| 92 | Depth tolerance
of blind slot | ±0.2mm |
| 93 | Maximum shipment
size | Size≤1200X600mm
(Double side, no test required) |
| 94 | Size≤1000X600mm
( Multilayer, no test required) |
| 95 | Minimum shipment
size | 10X10mm |
| 96 | PCB thickness
of HASL | 0.8-3.0mm(Hole less
0.5mm should be
use via-plug or mask-tent ) |
| 97 | HASL PCB Size | Size≤600X460mm |
| 98 | PCB thickness | 0.15-7.0mm |
| 99 | Depth of V groove | 0.8-3.2mm |
| 100 | Distance of non-continuous v-groove | ≥7mm |
| 101 | Max. drill diameter | Size≤6.5mm (Counterbore
or router will be used for
holes more than 6.5mm,
Min.tolerance ±0.1mm ) |
| 102 | Max. countersink
diameter | Size≤6.5mm Countersink
can be used counterbore
drill or router) |
| 103 | Distance of Bevel | Size≥11mm | Size≥5mm | Size≥5mm |
| 104 | Thickness of
peelable mask | 0.2-1.5mm ±0.15mm |
