Taconic Trf-45 0.61mm PCB Circuit Board Hard Gold Edge Connector
| Price: |
US $ 1.02/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
BIC-619-V6.19 |
| Final Foil External: |
1.5 Oz |
| Final Height Of PCB: |
0.9mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
Green |
| Colour Of Component Legend: |
White |
| Minimum / Maximum Holes: |
0.45/4.1mm |
| Minimum Trace And Space: |
5.4 Mil/6.3 Mil |
| Board Plating: |
0.0030" |
| Via: |
Plated Through Hole(Pth) |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Product Description
Company Profile
Bicheng Enterprise Limited mainly specializes in high frequency and microwave printed circuit
boards. We have rich experiences on the high frequency PCB in the application of power divider,
coupler, combiner, power amplifier, trunk amplifier, base station and 4G antenna etc. The dielectric
constant ranges from 2.2-10.3 etc. We keep inventory at any time for RO4350B, RO4003C, F4B
etc. and can provide quick sample service in time.
We're capable of supplying high frequency PCBs up to 32 layers inclusive of HDI technology, blind
and buried via, hybrid with FR-4 substrate etc.
High Frequency PCB
Flexible Printed Circuit
Metal Core PCB
PCB Board
Thechnology Information
Design For Manufacture | Serial NO. | Procedure | Item | Manufacturing capability |
Large volume
(S<100 m²) | Middle volume
(S<10 m²) | Prototype
(S<1m²) |
|
| 35 | Solder mask
(18um, 35um,
70um etc are
finished copper.
If not mentioned
copper, finished
1oz is the default
value ) | Maximum
via-plug
diameter | 0.5mm | 0.5mm | 0.5mm |
| 36 | Min.width
of solder
mask bridge | Green:5mil
(35um) | Green:4mil
(35um) | Green:4mil
(35um) |
| 37 | Yellow:5mil
(35um) | Yellow:4mil
(35um) | Yellow:4mil
(35um) |
| 38 | Blue:5mil
(35um) | Blue:4mil
(35um) | Blue:4mil
(35um) |
| 39 | Black:6mil
(35um) | Black:6mil
(35um) | Black:6mil
(35um) |
| 40 | White:6mil
(35um) | White:6mil
(35um) | White:6mil
(35um) |
| 41 | All of Matt:
6mil | All of Matt:
6mil | All of Matt:
6mil |
| 42 | Green:5mil
(70um) | Green:4mil
(70um) | Green:4mil
(70um) |
| 43 | Yellow:5mil
(70um) | Yellow:4mil
(70um) | Yellow:4mil
(70um) |
| 44 | Blue:5mil
(70um) | Blue:4mil
(70um) | Blue:4mil
(70um) |
| 45 | Black:6mil
(70um) | Black:6mil
(70um) | Black:6mil
(70um) |
| 46 | White:6mil
(70um) | White:6mil
(70um) | White:6mil
(70um) |
| 47 | Open solder
mask | 4mil(35um) | 4mil(35um) | 3mil(35um) |
| 48 | Solder mask
coverage | 4mil(35um) | 4mil(35um) | 3mil(35um) |
| 49 | Min.width of
solder mask
text | 9mil(35um) | 9mil(35um) | 8mil(35um) |
| 50 | Min.thickness
of Solder mask | 9um(35um) | 9um(35um) | 9um(35um) |
| 51 | Max.thickness
of solder mask | 30um(35um) | 30um(35um) | 30um(35um) |
| 52 | Silkscreen | Min.width of
silkscreen text | 6mil | 6mil | 5mil |
| 53 | Min.height of
silkscreen text | 35mil | 35mil | 30mil |
| 54 | Min.space from
silkscreen to
pads | 6mil | 6mil | 5mil |
| 55 | Colour of
silkscreen | White,
Black, Yellow |
| 56 | Carbon ink | Carbon ink
covers
conductor
or pads | 14mil | 13mil | 12mil |
| 57 | Mid distance
from
carbon ink
to pads | 12mil | 11mil | 10mil |
| 58 | Peelable
mask | Peelable
mask
covers
conductor
or pads | 8mil | 7mil | 6mil |
| 59 | Min.distance
from
peelable mask
to
pads | 14mil | 13mil | 12mil |
| 60 | Max.via-plug of Silk-screen
method | 2.0mm | 2.0mm | 2.0mm |
| 61 | Max. via-plug of
aluminum
foil method | 4.5mm | 4.5mm | 4.5mm |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
