Taiyo Solder Mask PCB Board Hybrid (Rogers and FR4) Tg 280
| Price: |
US $ 3.51/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-585-V5.85 |
| Board Thick: |
1.6mm |
| Surface Finish: |
HASL Lf |
| Out Layer Copper: |
35um (1 Oz) |
| Soldermask Color: |
Blue, Kuang Shun, Ksm-6189bl04 / Ksm-19h01 |
| Silkscreen Color: |
White, Taiyo, Ijr-4000 MW300 |
| Mininum Trace (Mil): |
20 Mil |
| Minimum Gap(Mil): |
15 Mil |
| RoHS Required: |
Yes |
| Warpage: |
≤0.25% |
| Function: |
100% Pass Electrical Test |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
Product Description
Company Profile
Bicheng Enterprise Limited can help you with following printed circuit boards.
A. Various kinds of PCB products- Double sided PCB
- Multilayer PCB up to 32 layers
- FR-4 PCB (Tg130, Tg170)
- High frequency PCB (RO4350B, RO4003C)
- Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
- Flexible PCB
B. Multiple technology on PCB- Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
- Impedance controlled PCB
- Heavy copper PCB
- Hybrid material PCB
C. Many discount policies for new customers- SMT stencil foil, free of charge
- Prototype shipping cost, free of charge
- Prototype test, free of charge
- PCB panelization, free of charge
D. High quality PCB services- Prototype PCB and production PCB
- Quick turn-around prototypes
- Door to door logistic service
- Hassle-free, one-to-one service
Printed Circuit Board
Aluminum PCB
High Frequency PCB
Flex PCB
PCB Capabilities (Bicheng Enterprise Limited 2017)
Layer Counts: 1-32
Substrate Material: FR-4(including High Tg 170, High CTI>600V); Aluminum based; RO4350B,
RO4003C; Polyimide, 94HB and FR-1 (upon request)
Maximum Size: Flying test: 900*600mm, Fixture test 460*380mm, No test 1100*600mm
Board Outline Tolerance: ±0.0059" (0.15mm)
PCB Thickness: 0.0157" - 0.3937" (0.40mm--10.00mm)
Thickness Tolerance(T≥0.8mm): ±8%
Thickness Tolerance(t<0.8mm): ±10%
Insulation Layer Thickness: 0.00295" - 0.1969" (0.075mm--5.00mm)
Minimum Track: 0.003" (0.075mm)
Minimum Space: 0.003" (0.075mm)
Outer Copper Thickness: 35µm--420µm (1oz-12oz)
Inner Copper Thickness: 17µm--420µm (0.5oz - 12oz)
Drill Hole (Mechanical): 0.0059" - 0.25" (0.15mm--6.35mm)
Finished Hole (Mechanical): 0.0039"-0.248" (0.10mm--6.30mm)
Diameter Tolerance (Mechanical): 0.00295" (0.075mm)
Registration (Mechanical): 0.00197" (0.05mm)
Aspect Ratio: 12:1
Solder Mask Type: LPI
Min Solder mask Bridge: 0.00315" (0.08mm)
Min Solder mask Clearance: 0.00197" (0.05mm)
Plug via Diameter: 0.0098" - 0.0236" (0.25mm--0.60mm)
Impedance Control Tolerance: ±10%
Surface Finish: HASL, HASL LF, ENIG, Immersion Tin, Immersion Silver, OSP, Gold Finger
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
More >
