Tb-1506 15A 600V Power Connector Fixed Terminal Block

Name: Tb-1506 15A 600V Power Connector Fixed Terminal Block
Brand: all-electronics-online.com
SKU: 714954755
Availability: InStock
Rating: 4.9 (117 reviews)

Price:	US $ 0.25/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	5000/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	Cable
Environmental Protection:	Resistance to Environmental
Connection Mode:	Threaded Connection
Shape:	Rectangle
Contact Termination Form:	Screws Fixed

Product Description

TB-2503 Fixed Terminal block

Rating: 600V, 25A, 6P Size: 55/30/19mm
Wire Size: 0.5-2.5 mm*m Screw Size: M8

Main Model: TB-1503, TB-1504, TB-1505, TB-1506, TB-1510, TB-1512, TB-2503, TB-2504, TB-2505, TB-2506, TB-2510, TB-2512, TB-4503, TB-4504, TB-4505, TB-4506, TB-4512, TB-60A/3P, TB-60A/4P, TB-100A/3P/4P

Wire Section: 0.5-1.5mm2, 0.5-2.5mm2, 0.5-4mm2
Rated Current/ Voltage: 15A/600V, 25A/600V, 45A/600V, 10A/660V.
Current: 15A, 25A, 35A, 45A, 60A, 100A
Poles: 3, 4, 5, 6, 10, 12

Housing Material: Polyphenyl or polycarbonate
Contact: Copper pieces, tin plated brass screws
Cover: Reinforced plastic, ensures heat-resistance, good toughness and no crack

Gerneral Product Information
Item number:	TB-1506
Rating:	600V, 15A, 6P
Size:	73.522.017.5mm (LWH)
Wire Size:	2.0 mm2 / AWG14
Screw Size:	M3

Dimensions [mm] (EXAMPLE:)
Item No.	Poles (P)	Length (L)	Width (W)	Height (H)
TB-1503	3	46.5	22 mm	17.5 mm
TB-1504	4	55.5
TB-1506	6	73.5
TB-1512	12	128.5

Product Features

?Molded from UL94-V2 material with excellent flame- and shock-resistance
?Sectional or one-piece construction. Easy and Flexible to form multipole assembly.
?Panel Mounting or free floating. Mounting holes are furnished at each end of the block.
?Marking paper strips and protective covers are available.
?Excellent for switchboard panel, control consoles, small motors, transformers, air conditioners, power distribution and similar applications.

Our company is a key electrical accessories manufacturer of terminal blocks and other cable accessories in China.

Our company is located in Yueqing, Wenzhou City, Zhejiang Province. It is a manufacturing and export company, specialized in producing components for kinds of lights, automobile and so on. They have gone through many authentications such as CQC, CE, RoHS. The main products are terminal blocks and wires, cable ties, cable clips, cable glands and copper inserts. They have entered the mafket of most parts in the world including Europe, the Middle East and Latin America. They are of good quality and sell well in many countries.

Our company manufactures products strictly according to IEC and national GB standards, and we have established a complete and improved quality management system according with ISO9002 standard system, We guarantee the products with competitive price, high quality and timely delivery. Besides, we can supply a complete set of after-sales service to our customers and help term expand their local market share.

We welcome you to contact us for more information and we are looking forward to chances of creating a long and mutually beneficial partnership with you. We do hope to cooperate very very well and develop rapidly with our joint efforts for mutual benefits.
