Nanjing Conpo Power Tech. Co., Ltd. >> TDGC2 Series Contact Voltage Regulator/Variable Transformer 1phase, Tdgc2-0.5/1/2/3/5/7/10/15/20/30/40kVA

TDGC2 Series Contact Voltage Regulator/Variable Transformer 1phase, Tdgc2-0.5/1/2/3/5/7/10/15/20/30/40kVA

TDGC2 Series Contact Voltage Regulator/Variable Transformer 1phase, Tdgc2-0.5/1/2/3/5/7/10/15/20/30/40kVA
Price: Negotiable/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 100/Piece
Pay Type: L/C,T/T,Western Union,Paypal,Money Gram
Prod Model: TDGC2-0.5/1/2/3/5/7/10/15/20/30/40KVA
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Phase: Single Phase
Current Type: AC
Frequency: 50Hz/60Hz
Usage: Reliable and Suitable for Any Load Equipment

Product Description

Feature:
This series energy-saying voltage regulator are made of imported silicon steel, it can successively adjust the output voltage(single-phase 0~250V), with the features of no waveform distortion, small volume, light weight, high efficiency, convenient use, reliable performance and so on.

Application:
It can be applied in industry, scientific experiment, public facilities and domestic appliances to achieve the goal of voltage regulating, temperature controlling, light regulating, power controlling and so on.

Specification:
Phase No.: Single phase
Input voltage: 220V/1Phase
Output voltage: 0~250V/1Phase
Frequency: 50Hz/60Hz
Efficiency: >95%

Remarks:
Custom-made specifications are acceptable.
Model Phase No. Rated power(KVA) Pkg size(cm) Unit per pkg
TDGC2-0.5KVA 1Phase 0.5 34x45x22 6
TDGC2-1KVA 1Phase 1 22x42x26 4
TDGC2-2KVA 1Phase 2 22x42x20 2
TDGC2-3KVA 1Phase 3 29x50x26 1
TDGC2-5KVA 1Phase 5 39x42x31 1
TDGC2-7KVA 1Phase 7 39x42x31 1
TDGC2-10KVA 1Phase 10 43x48x51 1
TDGC2-15KVA 1Phase 15 43x48x67 1
TDGC2-20KVA 1Phase 20 43x48x67 1
TDGC2-30KVA 1Phase 30 45x48x117 1
TDGC2-40KVA 1Phase 40 45x48x117 1

CONPO Power Tech. Co., Ltd specializes in producing Power Source as a member of China Power Supply Society. Since being founded, we has been insisting on the theoretic guideline of "Science & Technology is the first productive force" and holding up brand strategy as the guide, relying on forward understanding about power supply technology, perfect craft and unwearied pursuing to quality, we can show top quality power supply products, and set up fine image in Chinese market and abroad market.

CONPO has the modern workshops and advanced production devices, besides we always introduce technology positively, reform craft continuously, devote to researching and developing Voltage Stabilizer/Voltage Regulator, Uninterruptible Power Supply(UPS), Power Inverter, Solar Panel, Solar Controller, Solar Inverter and Solar Generator, Switching-mode Power Supply(SMPS), Transformer, Frequency Inverter etc. Power and Solar products. In addition, we try to find excellent administrators and technical talents, through years on working hard, we has been improved on the aspect of quality, power supply varieties, producing scale, management mode, so products manufactured by us have reached advanced technical level, they are not only popular with a great of customers in China, but also in foreign countries.

CONPO Products have been approved by Quality Supervision & Inspection(QSI), Insured by PICC, and also have CE, RoHS, UL, CCC certificates. We insist on the policy of developing by quality on the time, and also have passed ISO9001: 2000 Quality Management System Certificate. Relying on rich economic strength, fine production engineering, innovating management mode, we can dare to meet kinds of challenges from China entering WTO that is helpful for establishing reinforced foundation of international business.

We are keeping our business principle for " Approaching the first-class management, Producing the first-class products, Providing the first-class service". All CONPO staffs are working hard and constantly innovate. Honest CONPO are welcome to all users to fighting a better tomorrow hand in hand.
