Teflon PTFE Glassfiber Fabric Cloth

Name: Teflon PTFE Glassfiber Fabric Cloth
Brand: all-electronics-online.com
SKU: 710192515
Availability: InStock
Rating: 4.9 (65 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	200/Square Meter
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	(YS-9008AJ)-(YS-9090BJ)
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
High Temperature Resistant:	Super Release Surface
Application:	Switch Baseplate
Type:	Insulation Tape
Chemistry:	Organic Insulation
Material:	Fiberglass
Thermal Rating:	F 155
Maximum Voltage:	10KV~20KV

Product Description

Youngsun use excellent fiberglass as the weaving material to plain knit or specially knit into superior fiberglass basic cloth, coat it with fine PTFE resin then make it into various PTFE Teflon high temperature resistance cloth in different thickness and widths
Properties:

stable dimension, high intensity, elongation coefficient less 5 percent
good temperature resistance, 24 hours working temperature -70~260
low coefficient of friction and dielectric constant, good insulating ability
non stick, easy to clear stains and adhesives on the surface
good chemical resistance, it can resist all most of chemical medicines, acids, alkalis, and salt, it is fireproof, lower in aging.

Model	Colour	Thickness	Max Width	Tensile Strength	Temperature Range
YS-9008AJ	Brown	0.08mm	1250mm	500/480N/50mm	-140to360
YS-9008BJ	Black	0.08mm	1250mm	620/460N/50mm	-140to360
YS-9008Y	Black	0.08mm	1250mm	930/720N/50mm	-140to360
YS-9013AJ	Brown	0.13mm	1250mm	1100/1000N/50mm	-140to360
YS-9013BJ	Black	0.13mm	1250mm	1000/960N/50mm	-140to360
YS-9013Y	Black	0.13mm	1250mm	910/880N/50mm	-140to360
YS-9018AJ	Brown	0.18mm	1250mm	1600/1600N/50mm	-140to360
YS-9018BJ	Black	0.18mm	1250mm	1500/1500N/50mm	-140to360
YS-9025AJ	Brown	0.25mm	2800mm	2100/1800N/50mm	-140to360
YS-9025BJ	Black	0.25mm	2800mm	2800/2700N/50mm	-140to360
YS-9035AJ	Brown	0.35mm	3200mm	2700/2600N/50mm	-140to360
YS-9035BJ	Black	0.35mm	3200mm	2100/2200N/50mm	-140to360
YS-9040AJ	Brown	0.40mm	3500mm	2900/3100N/50mm	-140to360
YS-9040BJ	Black	0.40mm	3500mm	3000/2900N/50mm	-140to360
YS-9065AJ	Brown	0.65mm	4000mm	4200/4000N/50mm	-140to360
YS-9090AJ	Brown	0.90mm	4000mm	6300/5800N/50mm	-140to360
YS-9090BJ	Black	0.90mm	4000mm	6150/5300N/50mm	-140to360
