Thermal PCB 2.4mm Thick 0.095" Board Non-Conductive Via Fill

Price:	US $ 1.25/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	BIC-5.73-V5.73
Final Foil External:	1.0 oz
Final Height Of PCB:	1.6mm
Surface Finish:	OSP, Thickness >0.2 µm
Solder Mask Color:	None
Colour Of Component Legend:	None
Mininum Trace (Mil):	6 Mil
Minimum Gap(Mil):	9 Mil
Minimum / Maximum Holes:	0.9/2.3mm
Board Plating:	0.0029"
Test:	100% Electrical Test Prior Shipment
Type:	Rigid Circuit Board
Material:	Fiberglass Epoxy
Flame Retardant Properties:	V0
Dielectric:	PTFE 1.5mm

Product Description

Company Profile
Bicheng PCB, the quality is more stable. 10-year gold medal clients recommend you to use
Bicheng PCB.

1. Codec Tieline has won numerous awards for innovation in technology and thousands of
customers around the world rely on reliable broadcast solutions. High quality circuit board
is indispensable.

2. Telemetry UHS supplies innovative products and solutions to enable the transport of
diverse telecommunications products over broadband networks. A stable and good printed
circuit board plays an important role.
Don't just take our word for it. Read what Richard and Olaf have to say about Bicheng PCB.

"Kevin,
Received and tested the boards - thanks very much. These are perfect, exactly what we
needed.

Rgds
Rich "

"Hi Ruth,
I got the PCB today, and they are just perfect. Thank you for that.
I will memory your for my next PCB order. Please stay a little patience, my next order is
coming soon.
Kind regards from Hamburg
Olaf "

Email us today, we'll respond you within 8 hours. Still slow, take a phone and call us today.

High Frequency PCB

Flexible Printed Circuit

Metal Core PCB

PCB Board

Metal Core PCB Capability

NO.	Parameter	Value
1	Type of Metal Core	Aluminum, Copper, Iron
2	Model of Metal Core	A1100, A5052, A6061, A6063, C1100
3	Surface Finish	HASL, Immersion Gold, Immersion Silver, OSP
4	Thickness of Surface plating	HASL: Sn>2.54µm, ENIG: Au 0.025-0.1µm, Ni 2.5-5µm
5	Layer Count	1-4 Layers
6	Maximum of Board Size	23" x 46" (584mm×1168mm)
7	Mininum of Board Size	0.1969" x 0.1969" (5mm×5mm)
8	Board Thickness	0.0157" x 0.2362" (0.4-6.0mm)
9	Copper Thickness	0.5OZ(17.5µm),1OZ(35µm), 2OZ(70µm),3OZ(105µm), 4OZ(140µm) to 10oz (350µm)
10	Minimum Track Width	5mil (0.127mm)
11	Minimum Space	5mil (0.127mm)
12	Minimum Hole Size	0.0197" (0.5mm)
13	Maximum Hole Size	No limit
14	Minimum Holes Punched	PCB thickness <1.0mm: 0.0394" (1.0mm)
14	Minimum Holes Punched	PCB thikness 1.2-3.0mm: 0.0591" (1.5mm)
15	PTH Wall Thickness	>20µm
16	Tolerance of PTH	±0.00295" (0.075mm)
17	Tolerance of NPTH	±0.00197" (0.05mm)
18	Deviation of Hole Position	±0.00394" (0.10mm)
19	Outline Tolerance	Routing: ±0.00394" (0.1mm)
19	Outline Tolerance	Punching: ±0.00591" (0.15mm)
20	Angle of V-cut	30°, 45°, 60°
21	V-cut Size	0.1969" x 47.24" (5mm×1200mm)
22	Thickness of V-cut Board	0.0236" x 0.1181" (0.6-3mm)
23	Tolerance of V-cut Angle	±5º
24	V-CUT Verticality	≤0.0059" (0.15mm)
25	Minimum Square Slots Punched	PCB thickness < 1.0mm: 0.0315" x 0.0315" (0.8 x 0.8mm)
25	Minimum Square Slots Punched	PCB thickness 1.2-3.0mm: 0.0394" x 0.0394" (1.0 x 1.0mm)
26	Minimum BGA PAD	0.01378" (0.35mm)
27	Minimum Width of Solder Mask Bridge.	8mil (0.2032mm)
28	Minimum Thickness of Solder Mask	>13µm (0.013mm)
29	Insulation Resistance	1012ΩNormal
30	Peel-off Strength	2.2N/mm
31	Solder float	260ºC 3min
32	E-test Voltage	50-250V
33	Thermal Conductivity	0.8-8W/M.K
34	Warp or Twist	≤0.5%
35	Flammability	FV-0
36	Minimum Height of Component indicator	0.0059"(0.15mm)
37	Minimum Open Solder Mask on Pad	0.000394" (0.01mm)

PCB Classification --- Double sided PCB

Both sides of the circuit board are wired, but to use the two sides of the wire, we must have the
proper circuit connection between the two sides. The "bridge" between the circuits is called the
pilot hole (via). The via is filled with or coated with a small hole in the PCB. It can be connected
to the two sides of the wire. Because double sided PCB is twice larger in area than a single sided
PCB, it solves the difficulty that wiring staggered in single side PCB (through hole conduction to
the other side). It is more suitable for use in circuits that are more complex than a single sided
board.
