Thermal Stress Test Ceramic Materal PCB Board Black Solder Mask
| Price: |
US $ 1.05/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
BIC-648-V6.48 |
| Final Foil External: |
1.0 Oz |
| Final Height Of PCB: |
0.6mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
None |
| Colour Of Component Legend: |
None |
| Mininum Trace (Mil): |
7.87 Mil |
| Minimum Gap(Mil): |
5.9 Mil |
| RoHS Required: |
Yes |
| Warpage: |
0.56% |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Product Description
Company Profile
Bicheng Enterprise Limited which was founded in 2003 is a leading PCB expert that specializes in
supplying high-tech PCB in high mixed, fast prototype, small to medium volume. We're capable of
supplying PCBs up to 32 layers inclusive of HDI circuit boards, flexible circuits, rigid-flex boards,
hybrids, halogen-free boards, metal-based PCB, high frequency PCB, heavy copper (up to 12
oz) PCB etc. which are in the applications of high-tech products.
The manufacturing facility is certified with ISO9001, ISO14001 & TS16949.Our products are widely
used in Telecom, Industrial Control, Networks, Healthcare, & Automotive Industries.
High Frequency PCB
Flexible Printed Circuit
Metal Core PCB
PCB Board
Technology Information
Design For Manufacture| Serial NO. | Procedure | Item | Manufacturing capability |
Large volume
(S<100 m²) | Middle volume
(S<10 m²) | Prototype
(S<1m²) |
|
| 62 | Surface
finish | Thickness of
nickel of ENIG | 3-5um | 3-5um | 2-6.35um |
| 63 | Thickness of
Gold of ENIG | 0.05-0.1um |
| 64 | Thickness of
nickel of Gold
finger | 3-5um |
| 65 | Thickness of
Gold of Gold
finger | 0.1-1.27um |
| 66 | Thickness of
tin of HASL | 2.54-6.35um |
| 67 | Thickness of
OSP | 0.2-0.5um |
| 68 | Thickness
of tin of
Immersion
tin | 0.2-0.75um |
| 69 | Thickness
of silver of
Immersion
silver | 0.15-0.75um |
| 70 | Contour
process | Method of
contour
process | CNC milling,
V-CUT,
Break-out
tap, break-
out holes,
Punching |
| 71 | Minimum router | 0.8mm |
| 72 | Min.tolerance
of contour | ±0.15mm | ±0.13mm | ±0.1mm |
| 73 | Min.distance of
milling contour
(no copper
exposure) | 12mil | 10mil | 8mil |
| 74 | Angle of
V-CUT | 20,30,45,
60 ±5 degree |
| 75 | Degree of
symmetry of
V-CUT | ±6mil | ±5mil | ±4mil |
| 76 | Tolerance of
residual thickness
of V-CUT | ±6mil | ±5mil | ±4mil |
| 77 | Tolerance of
Chamfer angle
of Gold finger | ±5 degree | ±5 degree | ±5 degree |
| 78 | Tolerance of
residual thickness
of bevel edge of
gold finger | ±5mil | ±5mil | ±5mil |
| 79 | Min radius of
inner corner | 0.4mm |
| 80 | Min. distance
from edge to V-Cut (no copper
exposure) | 18mil
(1.6mm
Thick,
20 degree
V-groove
cutter) | 14mil
(1.6mm
Thick, 20
degree V-
groove cutter) | 12mil
(1.6mm
Thick, 20
degree V-
groove cutter) |
| 81 | 20mil
(1.6mm
Thick, 30
degree
V-groove
cutter) | 18mil
(1.6mm
Thick, 30
degree V-
groove cutter) | 16mil
(1.6mm
Thick, 30
degree V-
groove cutter) |
| 82 | 24mil
(1.6mm
Thick,
45 degree
V-groove
cutter) | 22mil
(1.6mm
Thick, 45
degree V-
groove cutter) | 20mil
(1.6mm
Thick, 45
degree V-
groove cutter) |
| 83 | 30mil
(1.6mm
Thick, 60
degree V-groove cutter) | 28mil
(1.6mm
Thick, 60
degree V-
groove cutter) | 26mil
(1.6mm
Thick, 60
degree V-groove cutter) |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
A) Various kinds of PCB products
Double sided PCB
Multilayer PCB up to 32 layers
FR-4 PCB (Tg130, Tg170)
High frequency PCB (RO4350B, RO4003C)
Aluminum PCB (1W/MK, 2W/MK, 3W/MK)
Flexible PCB
HDI PCB Board
B) Multiple PCB technology to meet the market demands
Blind via PCB, Via in pad PCB, Fine pitch BGA PCB
Impedance controlled PCB
Heavy copper PCB
Hybrid material PCB
C) Many discount policies for new customers
SMT stencil foil, free of charge
Prototype shipping cost, free of charge
Prototype test, free of charge
PCB panelization, free of charge
D) High quality PCB services
Engineering design prevents problems from occurring in pre-production.
Meet your PCB needs from prototype to mass volume production.
Eligible products rate of first production: >95%
Delivery on time: >98%, door to door shipment service
Customer complaint rate: <1%
Choose BichengPCB means you choose hassle free.
