Thick Copper PCB Circuit Board Taconic Tla-6 0.94mm Soft Gold

Name: Thick Copper PCB Circuit Board Taconic Tla-6 0.94mm Soft Gold
Brand: all-electronics-online.com
SKU: 836304905
Availability: InStock
Rating: 4.8 (30 reviews)

Price:	US $ 1.02/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	BIC-675-V6.75
Final Foil External:	1.5 Oz
Final Height Of PCB:	0.8mm
Surface Finish:	HASL Lead Free
Solder Mask Color:	Green
Colour Of Component Legend:	White
Minimum Trace And Space:	6.98 Mil/6.28 Mil
Minimum / Maximum Holes:	0.3/1.2mm
Via:	Via Tented
Board Plating:	0.0030"
Test:	100% Electrical Test Prior Shipment
Type:	Rigid Circuit Board
Flame Retardant Properties:	V0
Dielectric:	RO4003c
Material:	Hydrocarbon/Woven Glass
Insulation Materials:	Glass Reinforced Hydrocarbon

Product Description

Company Profile

Bicheng Enterprise Limited serves global clients from Shenzhen, China since 2003.

Variety of PCB technology to meet the market demands
HDI board
Heavy copper board
Hybrid material board
Blind via board
High frequency board
Metal core board
Immersion gold board
Multilayer board
Backplane board
Gold finger board

High Frequency PCB

Flexible Printed Circuit

Metal Core PCB

PCB Board

Technology Information
RO4350B & RO4003C Data Sheets

Property	Typical Value		Direction	Units	Condition	Test Method
	RO4003C	RO4350B
Dielectric Constant, εr Process	3.38±0.05	3.48±0.05	Z	-	10 GHz/23ºC	IPC-TM -650 2.5.5.5 Clampled Stripline
Dielectric Constant, εr Design	3.55	3.66	Z	-	8 to 40 GHz	Differntial Phase Length Method
Dissipation Factor Tan, δ	0.0027 0.0021	0.0037 0.0031	Z	-	10 GHz/23ºC 2.5 GHz/23ºC	IPC-TM -650 2.5.5.5
Thermal Coefficient of εr	40	50	Z	ppm/ºC	minus 50ºC to 150ºC	IPC-TM -650 2.5.5.5
Volume Resistivity	1.7 x 10¹º	1.2 x 10¹º		MΩ·CM	COND A	IPC-TM -650 2.5.17.1
Surface Resistivity	4.2 x 10^9	5.7 x 10^9		MΩ	COND A	IPC-TM -650 2.5.17.1
Electrical Strenghth	31.8 (780)	31.2 (780)	Z	KV/mm (V/mil)	0.51mm (0.020")	IPC-TM -650 2.5.6.2
Tensile Modulus	19650(2850) 19450(2821)	16767 (2432) 14153 (2053)	X Y	Mpa(ksi)	RT	ASTM D638
Tensile Strength	139(20.2) 100(14.5)	203(29.5) 130(18.9)	X Y	Mpa(ksi)	RT	ASTM D638
Flexural Strength	276 (40)	255 (37)		Mpa(kpsi)		IPC-TM -650 2.4.4
Dimensional Stability	<0.3	<0.5	X,Y	mm/m (mils/inch)	after etch E2/150ºC	IPC-TM -650 2.4.39A
Coefficient of Thermal Expansion	11 14 46	10 12 32	X Y Z	ppm/ºC	minus 55ºC to 288ºC	IPC-TM -650 2.4.41
Tg	>280	>280		ºC TMA	A	IPC-TM -650 2.4.24
Td	425	390		ºC TGA		ASTM D3850
Thermal Conducvitity	0.71	0.69		W/m/ºk	80ºC	ASTM C518
Moisture Absorption	0.06	0.06		%	48 hrs immersion 0.060" sample Temperature 50ºC	ASTM D570
Density	1.79	1.86		gm/cm³	23ºC	ASTM D792
Copper Peel Strength	1.05 (6.0)	0.88 (5.0)		N/mm (pli)	after solder float 1 oz. EDC Foil	IPC-TM -650 2.4.8
Flammability	N/A	V-0				UL 94
Lead-Free Process Compatible	Yes	Yes

Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.

The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.

Different plant scale to suit for your requirements

16000 square meter factory building

30000 square meter month capability

8000 types of PCB per month

ISO9001, ISO14001, TS16949, UL Certified

We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.

A) Various kinds of PCB products

Double sided PCB

Multilayer PCB up to 32 layers

FR-4 PCB (Tg130, Tg170)

High frequency PCB (RO4350B, RO4003C)

Aluminum PCB (1W/MK, 2W/MK, 3W/MK)

Flexible PCB

HDI PCB Board

B) Multiple PCB technology to meet the market demands

Blind via PCB, Via in pad PCB, Fine pitch BGA PCB

Impedance controlled PCB

Heavy copper PCB

Hybrid material PCB

C) Many discount policies for new customers

SMT stencil foil, free of charge

Prototype shipping cost, free of charge

Prototype test, free of charge

PCB panelization, free of charge

D) High quality PCB services

Engineering design prevents problems from occurring in pre-production.

Meet your PCB needs from prototype to mass volume production.

Eligible products rate of first production: >95%

Delivery on time: >98%, door to door shipment service

Customer complaint rate: <1%

Choose BichengPCB means you choose hassle free.
