Thw #10 10AWG 10 Gauge Solid Red Building Electrical Cable Wire

Name: Thw #10 10AWG 10 Gauge Solid Red Building Electrical Cable Wire
Brand: all-electronics-online.com
SKU: 796944955
Availability: InStock
Rating: 4.5 (138 reviews)

Price:	US $ 0.17-0.42/Meter
Min Order:	1000/Meter
Pay Type:	L/C,T/T,D/P,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	THW
Item Name:	PVC Insulated Thw Cable
Rated Voltage:	600V
Referred Standard:	UL 83
Number Of Cores:	1
Number Of Wires:	7/19
Color:	Any Color
Type:	Insulated
Conductor Type:	Solid
Conductor Material:	Copper
Insulation Material:	PVC
Certification:	RoHS
Application:	Building
Sheath Material:	Only Insulation
Range Of Application:	Building
Brand:	Joca

Product Description

THW #10 10AWG 10 Gauge Solid Red Building Electrical Cable Wire

Applications

THW cable is suitable for various commercial and industrial applications. These cables may be installed in wet or
dry locations, indoors or outdoors, in raceways, underground ducts (ask about our preinstalled cable-in-conduit
products), aerial or direct buried.
THW cable is NEC-compliant for continuous operations at 75° C in wet and dry locations.

Specifications and Ratings
- UL Type THW
- The insulation is suitable for use in wet or dry locations at a temperature not exceeding 75° C
- RoHS compliant
- Oil resistant
- CT USE (#1/0 AWG and larger)

Products Parameters

CONDUCTORS: Bare copper or tinned copper conductors
conductors are available as options.

INSULATION: Heat and moisture resistant polyvinyl chloride(PVC) meeting the requirements of ICEA S-95-658 (NEMA WC 90)
UL 83 for Type THW and wires. The insulation is suitable for use in wet or dry locations at a conductor temperature not exceeding
75° C for normal operation.

ASSEMBLY: Single conductor cables can be paralleled or multiplexed for more efficient installations. Single conductor cables
can also be pre-installed in conduit.

PVC Insulated Electrical THW Building Wire
Standards: UL83, CSA C22.2No.75-03, UL1581
Conductor Size AWG (mm2)	Strand Class	Strands	Nominal Insulation Thickness in(mm)	Nominal Cable O.D. in(mm)	Approximate Cable Weight Lbs/Mft(Kg/Km)
14AWG(2.08)	Class B	7	.030 (0.72)	0.140 (3.6)	18 (27)
12AWG(3.31)	Class B	7	.030 (0.73)	0.160 (4.1)	28 (42)
10AWG(5.26)	Class B	7	.030 (0.74)	0.180 (4.6)	42 (63)
8AWG(8.37)	Class B	7	.045 (1.1)	0.250 (6.3)	69 (103)
6AWG(13.3)	Class B	7	.060 (1.5)	0.310 (7.9)	110 (164)
4AWG(21.2)	Class B	7	.060 (1.5)	0.360 (9.1)	165 (246)
2AWG(33.6)	Class B	7	.060 (1.5)	0.420 (10.7)	250 (373)
1/0AWG(53.5)	Class B	19	.080 (2.0)	0.540 (13.7)	400 (597)
2/0AWG(67.4)	Class B	19	.080 (2.0)	0.580 (14.7)	500 (746)
4/0AWG(107)	Class B	19	.080 (2.0)	0.690 (17.5)	755 (1126)

...All the cables are certificated by CCC, and some are listed by UL, VDE, TUV, we look forard to more scale co-operation with Jiukai as their good quality items&competitive price..."

----Alex Jones, G. M of Saudi Cable Wholesaler

Jiukai holding group is a collection of science, industry and trade as one of the enterprise group. Group total registered capital of 250 million yuan, covers an area of 180000 square meters, construction area of 100000 square meters. Group have cables in today's domestic and foreign advanced equipment, more than 800 sets, the annual production capacity of 1.6 billion yuan, staff more than 600, national and over seas has nearly 30 offices or branches. Group core subsidiary Shanghai jiukai wire and cable Co., Ltd., Jiukai communication technology (Shanghai) Co., Ltd., Wuxi qunxing wire cable Co., Ltd.

Shanghai Jiukai Wire & Cable Co., Ltd is a professional manufacturer of wires & cables, including Electrical Cable, Low Voltage/Medium Voltage/ High Voltage Power Cable, Speaker Cables, Telephone Cable, RF Cable, Solar Cable, Building Wire, UL approved Cable, CE approved Cable, Welding Cable, Submersible Pump Cable. Conductor materials are varied from tinned copper, bare copper, CCA, CCS, aluminium. Insulation & jacket materials are available for PVC, PE, XLPE, Rubber, silicon. Rated voltages are for 300V below, 300/300V, 300/500V, 45/750V, 600/1000V, 3.6/6KV, 10KV, 26/36KV and 36KV above.
