Tll Tees Bolted Aluminum Cable Connector

Prod Model:	TLL
OEM:	Accept
Sample:	Free
Bolts & Nuts, Washers:	Steel, Hot DIP Galvanized.
Gender:	Female
Application:	Power

Product Description

TLL Tees Bolted Aluminum Cable Connector

Application:
Tees Bolted connector are used connecting aluminum-aluminum or aluminum-copper conductor combinations.

Features:
(1)Clamping bolts have hex-stops for one-wrench installation.
(2)Contact sealant is recommended.
(3)Cable to cable.

Material:
Body & keeper: aluminum alloy
Bolts & nuts, washers: steel, hot dip galvanized.




Type	Suitable Conductor Main/Tap	Dimensions(mm)
		Φ1	Φ2	H	L
TLL-1/1	7.5~10.0/7.5~10.0	11	11	101	115
TLL-2/1	10.5~14/7.5~10.0	15	11	101	115
TLL-2/2	10.5~14.0/10.5~14.0	15	15	101	116
TLL-3/1	14.5~17.5/7.5~10.0	18	11	113	115
TLL-3/2	14.5~17.5/10.5~14.0	18	15	113	116
TLL-3/3	14.5~17.5/14.5~17.5	18	18	113	116
TLL-4/1	18.0~22.0/7.5~10.0	22	11	113.5	115
TLL-4/2	18.0~22.0/10.5~14.0	22	15	113.5	116
TLL-4/3	18.0~22.0/14.5~17.5	22	18	113.5	116
TLL-4/4	18.0~22.0/18.0~22.0	22	22	113.5	117
TLL-5/1	23.0~29.5/8.0~12.0	30	12	180	130
TLL-5/2	23.0~29.5/11.0~16.0		16
TLL-5/3	23.0~29.5/14.5~17.5		18
TLL-5/4	23.0~29.5/18.0~22.5		23
TLL-5/5	23.0~29.5/23.0~29.5		30
TLL-6/1	30.0~35.0/8.0~12.0	36	12	185	150
TLL-6/2	30.0~35.0/11.0~16.0		16
TLL-6/3	30.0~35.0/14.5~17.5		18
TLL-6/4	30.0~35.0/18.0~22.5		23
TLL-6/5	30.0~35.0/23.0~29.5		30
TLL-6/6	30.0~35.0/30.0~35.0		36
