Triphase on Grid 20kwp Solar Inverter

Triphase on Grid 20kwp Solar Inverter
Price: US $ 1210-1640/Piece
Min Order: 5/Piece
Pay Type: L/C,T/T,Western Union,Paypal
Prod Model: CBT20kTL

Product Description

*Features:
a.The most optimal transformer topology
b. High conversion efficiency
c.Double/Single way MPPT input,and a wider voltage range
d.More reasonable structure design
e.More simple localization Settings
*Flexibility:
a.Protection grade IP65, adapt to the outdoor all kinds of bad weather
b.Simple and easy installation, maintenance free
c.RS485/WIFI(optional)
d.Multi-language display
*Reliability:
a.Safety and stable automatical protection including overvoltage,low voltage,anti-islanding,short circuit,over-load protection.
b.Five years standard waranty time,and the longest would reach 20years.
*Certificates:
CQC,VDE-AR-N4105,VDE126-1-1,AS4777,IEC61727,IEC62116
 Specification
DC inputAC outputEfficiencyGeneral data
Maximum DC Power26000W
Maximum DC Voltage:1000V DC
MPPT voltage range:200V DC
Full load MPPT voltage range:200V DC
Maximum input circuit:25A*2
MPPT tracking no.:2/2
AC rated power:20KW
Maximum apparent power communication:25KVA
Maximum output circuit:29A
AC rated voltage:3/N/PE 230V/400V AC (25KW is only 277V/480V AC)
AC frequency:50HZ/60HZ
Power factor, can be adjusted:0.8 advance-0.8 lag
Harmonic distortion:<3%
Maximum efficiency:98.4%
European efficiency:98.1%


Size(Width/Height/Depth):505/525/245mm
Weight:37kgs
Working temperature:-25 ºC-+60 ºC
Protection grade:IP65
The cooling way:Natural
Internal friction at night:<1W
Topology:No transformer
Display:LCD
Humidity:0-95%,non-condensing
Communication interface:RS485/WIFI(optional)
