Name: UL Certificated Good Supplier From China XLPE Electrical Wire
Brand: all-electronics-online.com
SKU: 836745245
Availability: InStock
Rating: 4.7 (131 reviews)

Price:	US $ 0.1-0.2/Meter
Min Order:	6100/Meter
Pay Type:	Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	3173
Type:	Insulated
Conductor Type:	Stranded
Insulation Material:	XLPE
Certification:	CSA, Iatf16949
Application:	Home Application,LED Lamp, Oven,Machine
Conductor Material:	Tinned Copper
Sheath Material:	XLPE
Range Of Application:	Home Application,LED Lamp, Oven,Machine
Brand:	Mysun

Product Description

UL certificated Good Supplier from China XLPE Electrical Wire

Specifications:

Nominal voltage: 600V

Temperature range: 125C

Standard: UL 758

Conductor: Tinned copper

Insulation: XLPE

Product dimensions:

Conductor			Insulation		Max.cond resistance (Ω/km)	Unit Length (m)(Ft)
Size (AWG)	Construction (No./mm)	Diameter (mm)	Nominal Thickness (mm)	Diameter (mm)	Max.cond resistance (Ω/km)	Unit Length (m)(Ft)
26	7/0.16	0.48	0.78	2.04	143	305/1000
24	11/0.16	0.60		2.16	89.3
22	17/0.16	0.76		2.32	56.4
20	21/0.18	0.94		2.49	35.2
18	16/0.254	1.18		2.73	22.2
16	26/0.254	1.50		3.06	14
14	41/0.254	1.89		3.45	8.78
12	65/0.254	2.37		3.93	5.53
10	105/0.254	3.02		4.58	3.476
9	133/0.254	3.36		4.92	2.73

Shenzhen Mysun Insulation Materials Co., Ltd. is a company of producing, selling and trading all kinds have UL, cUL, CSA, VDE, CCC, SGS, Tü V certified high temperature wire and wire harness since 1999.

Products are widely used in home appliances, lighting, medical equipments, office facilities, thermal electronics and industrial machine. Products are with good appearance, high-quality, safety application and environmental- friendly.
