UL5107 450c Rated Temperature Electrical Wire for Heating Element

Name: UL5107 450c Rated Temperature Electrical Wire for Heating Element
Brand: all-electronics-online.com
SKU: 838478615
Availability: InStock
Rating: 4.7 (77 reviews)

Price:	US $ 0.2-3/Meter
Min Order:	6100/Meter
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	UL5107
Rated Voltage:	600V
Rated Temp:	450c
Color:	White, Black, Red, Brown, Yellow, Blue etc
Type:	Insulated
Conductor Type:	Stranded
Certification:	RoHS
Application:	Internal Wire
Conductor Material:	Nickel-Plated Copper
Sheath Material:	Fiberglass
Insulation Material:	Mica
Range Of Application:	VW-1
Brand:	Mysun

Product Description

Product dimensions:

Conductor			Insulation			Unit Length (m)
Size (AWG)	Construction (No./mm)	Diameter (mm)	Mica Thickness (mm)	Glass Thickness (mm)	Diameter (mm)	Unit Length (m)
26	7/0.16	0.48	≥0.635	0.181	≥2.15	305
24	7/0.20	0.61			≥2.25
22	7/0.25	0.77			≥2.40
20	7/0.31	0.94			≥2.60
18	16/0.254	1.19			≥2.85
16	26/0.254	1.49			≥3.15
14	41/0.254	1.87			≥3.50	200
12	65/0.254	2.36	≥0.762	0.381	≥4.65	100
10	35/0.45	3.06			≥5.35
8	67/0.40	3.75			≥6.05
6	266/0.254	4.75			≥7.05
4	420/0.254	6.02			≥8.25

Service
Shipment:
1. by express
2. by sea

Payment terms:
LC, TT, Western Union, Money Gram and PayPal

Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days

Shenzhen Mysun Insulation Materials Co., Ltd. is a company of producing, selling and trading all kinds have UL, cUL, CSA, VDE, CCC, SGS, Tü V certified high temperature wire and wire harness since 1999.

Products are widely used in home appliances, lighting, medical equipments, office facilities, thermal electronics and industrial machine. Products are with good appearance, high-quality, safety application and environmental- friendly.
