Undertile Heating Cable230V VDE CE Approved

Name: Undertile Heating Cable230V VDE CE Approved
Brand: all-electronics-online.com
SKU: 677455515
Availability: InStock
Rating: 5 (57 reviews)

Price:	US $ 0.8/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	SHDN-20W
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Diameter:	2 to 6mm
Voltage:	230V
Power:	20W/M

Product Description

Undertile Heating Cable230V VDE CE approved
5-18W/m
Dual conductor(the first generation and the second generation)
Single conductor
CE approved

The technical specifications are:
SHDN-18-SS single conductor type
SHDN-18-DD twin conductor type

General:
Cable Type: Single \or twin conductor with Screen
Rated Voltage: As request
Watts per Meter: 18 W/m
Cold Tail Length: 1X 2-3m
Conductor Insulation: PTFE (teflon)
Shield: Aluminum foil or Tin coated copper wire shield net
Sheath: PVC or PTFE

Size	Power/W	Voltage	Resistance @20oC+10/-5%	Length(m)	The power line length
SHDN-20-15M(A)	300	230	176.33	15	3C 0.5mm2 L=2M black
SHDN-20-25M(A)	500	230	105.80	25	3C 0.5mm2 L=2M black
SHDN-20-30M(A)	600	230	88.17	30	3C 0.5mm2 L=2M black
SHDN-20-35M(A)	700	230	75.57	35	3C 0.75mm2 L=2M black
SHDN-20-42.5M(A)	850	230	62.24	42.5	3C 0.75mm2 L=2M black
SHDN-20-60M(A)	1200	230	44.08	60	3C 0.75mm2 L=2M black
SHDN-20-80M(A)	1600	230	33.06	80	3C 1.0mm2 L=2M black
SHDN-20-90M(A)	1800	230	29.39	90	3C 1.0mm2 L=2M black
SHDN-20-100M(A)	2000	230	26.45	100	3C 1.0mm2 L=2M black
SHDN-20-120M(A)	2400	230	22.04	120	3C 1.5mm2 L=2M black
SHDN-20-140M(A)	2800	230	18.89	140	3C 1.5mm2 L=2M black
SHDN-20-160M(A)	3200	230	16.53	160	3C 1.5mm2 L=2M black

Jiangyin Senphus Electrical Material Co., Ltd is a new Hi-tech enterprise of heating alloy, heating cable/mat, heating wire, silicone rubber heater, drum silicone rubber heater, thermostat, which is engaging in R&D, manufacture and sale.

We have our own alloy smelting factory, possessing first-class production and advanced research facilities, so that we guarantee the top quality of our products. We have already passed ISO9001 quality management system and achieved the examination report of National Center for quality Supervision & Test of Electric Wire & Cable, and gained the European Union CE certification, UL certificate, GS Certificate, electromagnetic radiation certification, SGS and REACH certification.

Heating cable/wire and temperature controller system are widely used in wind power blades, construction heating, pipeline heating, outdoor snow melting, soil heating field and so on. Silicone rubber heater are widely used in electrical household appliance, spaceflight, petroleum, metallurgy, military project, chemical, electric power, medical appliance, mechanism, outdoor communication, automobile, etc. Industry.

Our products have been exported to America and Europe, Africa, Southeast Asia, like USA, Canada, England, France, Holand, Poland, Peru, South Africa, Italy, Greece, Thailand, India, Hongkong, etc. More than thirty countries and areas.

Our company always persist in"reputation first, quality high and customers supreme" management ideal. We will use great products, competitive price, professional service to cooperate with you and gain win-win!

OEM is welcome! !
