UPS Inverter with Built in AC Charger 4800W Pure Sine
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
10/Piece |
| Pay Type: |
T/T,Western Union,Money Gram |
| Prod Model: |
PSC 6KVA-48 / PSC 6KVA-96 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Phase&Wave Form: |
Single Phase & Pure Sine Wave |
| Frequency: |
50Hz / 60Hz (Auto Detection) |
| AC Voltage: |
120VAC/230VAC or 220/230/240VAC |
| Display: |
LCD |
| Charge Current Adjustable: |
Yes |
| Can Connect Generator: |
Yes |
| Power Factor: |
0.8 |
| Color: |
Black |
| Warranty: |
2 Years |
| Delivery Time: |
1000PCS Within 15days |
Product Description
Applications:
3KVA-6KVA PSC series high frequency pure sine wave Inverter with charger is mainly used for solar power station; home solar power systems, mobile solar power system and DC wind solar generating systems or hybrid power system.
Main Features:
1.LCD digital display will show voltage, frequency, battery and load information in real time.
2.Built-in AC charger, 10A and 20A
3.High DC-AC conversion efficiency, >90%
4.High-frequency switching technology for compact size and light weight.
5.pure sine wave output available for sensitive loads.
6.Intelligent cooling fan,speed control determined by loads
7.Multiple protection: Input low voltage / Overload / Short circuit / Low battery alarm / Input over voltage / over temperature.
8. Advanced MCU microprocessor control technology, high reliability
Parameter
| Model | PSC 3KVA-24 | PSC 6KVA-48 | PSC 6KVA-96 |
| INPUT Voltage Range | 180-270VAC(Nominal) OR 100-270VAC(General/wide) |
| Rated Output power | 3000VA/2400W | 6000VA/4200W(4800W) | 6000VA/4200W(4800W) |
| Surge Rating | 4800W | 8400W | 8400W |
| Power factor | 0.8 | 0.7/0.8 | 0.7/0.8 |
Capable of starting
electic power | 1.5HP | 2.5HP | 2.5HP |
| Norminal Input Voltage | 220/230/240VAC |
| Norminal Input frequency | 50Hz or 60Hz (Auto detection) |
| Output Voltage | 220/230/240VAC±10% rms |
| Output frequency | 50Hz or 60Hz ±1Hz |
| Norminal Efficiency | >90%(@Norminal DC input;>60% R load) |
| Over-Load protection | fault after 5s 150% ~200% load |
| fault after 10s @ 110%~150% load |
| Norminal Charge current | 10A @ Vi/P<170VAC | 20A(95-175v)gen/wide only | 10A(95-175v) gen/wide only |
| 20A @ Vi/P=230VAC | 35A(175-275v) @35A setting | 20A(175-275v) @ 20A setting |
| 10A @ Vi/P>280VAC | 20A(175-275v) @25A setting | 10A(175-275v) @10A setting |
| Output Wave form | Pure sine wave |
| Norminal Input Voltage | 24Vdc | 48Vdc | 96Vdc |
| Charge voltage | 27Vdc | 54Vdc | 108Vdc |
| Over charge protection | Bat.V≥30Vdc,
Fault buzzer alarm | Bat.V≥60Vdc,
Fault buzzer alarm | Bat.V≥120Vdc,
Fault buzzer alarm |
| Output short circuit protection | 30A Circuit Breaker | 40A Circuit Breaker |
| Relative Humidity | 5% to 95% non condensing |
| Operating temperature | 0ºC-45ºC |
| Storage temperature | -15ºC-60ºC |
| Altitude optional | Elevation:0-1500m |
| Dimensions(L×W×H) | 330×269×77mm | 430×350×105mm |
| Net Weight (kg) | 4.9 | 8.5 | 8.5 |
Trading terms for reference:
Delivery time: 15days-25days, below 1000pcs within 15days, above 1000pcs within 25days.
Payment terms: TT, LC, Western Union, Money gram.
Warranty: 2 years, 1%-2% spare parts.
