USA UL Listed Power Cord Soow Sow Sjow Sjoow 16/3 18/3 14/3 12/3 18/4 Cable
| Price: |
US $ 0.23-0.25/Foot |
| Min Order: |
20000/Foot |
| Pay Type: |
L/C,T/T |
| Prod Model: |
SOOW Cable |
| Products Name: |
Flexible Cords, Soow, Sjoow |
| UL Listed Type: |
Soow, Sjoow, Sjeoow, Sto |
| Standard: |
UL62 |
| Rated Voltage: |
Low Voltage 300V, 600V |
| Insulation: |
Epr, EPDM, Ep |
| Sheath: |
CPE, Sun Resistance, Oil Resistance, Water Resista |
| Working Temperture: |
Max 90 Degree or 105degre |
| RoHS: |
Yes |
| Sheath Color: |
Black |
| Msha: |
Available |
| Type: |
Insulated |
| Conductor Type: |
Stranded |
| Conductor Material: |
Copper |
| Insulation Material: |
Rubber |
| Certification: |
RoHS |
| Brand: |
Renda |
| Sheath Material: |
Rubber, CPE |
| Application: |
Industrial, Mining |
Product Description
USA UL Listed power cord soow sow sjow sjoow 16/3 18/3 14/3 12/3 18/4 cable
APPLICATIONTYPE SOOW Cable is for use in heavy-duty industrial applications where flexibility and durability is required. SOOW is designed for extra hard usage on industrial equipment, heavy tools, motor and welding leads, power extensions, portable machinery, sound equipment, portable stage lights, marine dockside power and mining applications. Constructed of color-coded synthetic oil, ozone and water resistant rubber (EPDM) insulation and an oil resistant thermoset chlorinated polyethylene (CPE) jacket, SOOW is rated for indoor/outdoor use.SOOW flexible rubber cords carry a 600 volt rating. They are also manufactured as a 300 volt rated Junior Service cord designated as SJOOW. Using the key, a SJEOOW cord is a 300 volt (junior service) elastomer plastic oil resistant inner and outer jacket portable cord.
Applications
- Portable tools
Industrial and processing equipment
Construction equipment
Cranes and hoists
Track systems
Battery chargers
Portable appliances
Small motors and associated machinery
Electrical equipment exposed to oils, solvents, flame, or moisture
STANDARDS & REFERENCESType SOOW Cords/Cable meets or exceeds the applicable requirements of the following standards and
specifications:
UL Standard 62 for Flexible CordsCSA Standard 22.2 No. 49 for Flexible CordsMSHA flame resistance for mining applicationsNEC Article 400RoHS Compliant
SOOW offers: • Excellent resistance to oils, acids, chemicals, water, ozone, extreme temperatures, cuts, tears and abrasion • Sunlight resistant • Flame retardant • Indoor/outdoor rated • Highly flexible • Maximum continuous conductor temperature: 90°C DRYCONSTRUCTIONConductors: Bare, annealed copper per ASTM B-3 Flexible, bunch-stranded per UL-62Separator: A paper tape is applied between the conductor and insulation to facilitate stripping.Insulation: Color coded synthetic rubber (EPDM) oil and water resistant per UL-62Jacket: Black Chlorinated Polyethylene (CPE)Cabling: Conductors are assembled round with fillers as needed.Temperature Range: -40°C to +90°CVoltage Rating: 600 Volts for SOOW,300 Volts for SJOOW Conductor Size (AWG) | Conductor
Stranding | Nominal
Insulation
Thickness | Nominal
Jacket
Thickness | Nominal
Overall
Diameter
(in) | Weight | Ampacity |
| n | / | AWG/inch | mil | mil | in | lbs/1000ft | A |
| 2*18AWG | 16 | / | 30 | 30 | 60 | 0.33 | 70 | 10 |
| 3*18AWG | 16 | / | 30 | 30 | 60 | 0.35 | 80 | 10 |
| 4*18AWG | 16 | / | 30 | 30 | 60 | 0.37 | 96 | 7 |
| 2*16AWG | 26 | / | 30 | 30 | 60 | 0.36 | 86 | 13 |
| 3*16AWG | 26 | / | 30 | 30 | 60 | 0.37 | 99 | 13 |
| 4*16AWG | 26 | / | 30 | 30 | 60 | 0.41 | 119 | 10 |
| 2*14AWG | 41 | / | 30 | 45 | 80 | 0.49 | 155 | 18 |
| 3*14AWG | 41 | / | 30 | 45 | 80 | 0.51 | 179 | 18 |
| 4*14AWG | 41 | / | 30 | 45 | 80 | 0.56 | 215 | 15 |
| 2*12AWG | 65 | / | 30 | 45 | 95 | 0.56 | 206 | 25 |
| 3*12AWG | 65 | / | 30 | 45 | 95 | 0.58 | 239 | 25 |
| 4*12AWG | 65 | / | 30 | 45 | 95 | 0.63 | 290 | 20 |
| 2*10AWG | 104 | / | 30 | 45 | 95 | 0.62 | 266 | 30 |
| 3*10AWG | 104 | / | 30 | 45 | 95 | 0.66 | 316 | 30 |
| 4*10AWG | 104 | / | 30 | 45 | 95 | 0.72 | 385 | 25 |
| 3*8AWG | 133 | / | 29 | 60 | 110 | 0.83 | 505 | 40 |
| 4*8AWG | 133 | / | 29 | 60 | 125 | 0.93 | 646 | 35 |
| 5*8AWG | 133 | / | 29 | 60 | 125 | 0.93 | 684 | 35 |
| 3*6AWG | 133 | / | 27 | 60 | 125 | 0.95 | 694 | 55 |
| 4*6AWG | 133 | / | 27 | 60 | 140 | 1.07 | 885 | 45 |
| 5*6AWG | 133 | / | 27 | 60 | 140 | 1.07 | 946 | 45 |
| 3*4AWG | 133 | / | 0.0177 | 60 | 140 | 1.09 | 952 | 70 |
| 4*4AWG | 133 | / | 0.0177 | 60 | 155 | 1.22 | 1210 | 60 |
| 5*4AWG | 133 | / | 0.0177 | 60 | 155 | 1.22 | 1304 | 60 |
| 3*2AWG | 133 | / | 0.0223 | 60 | 155 | 1.26 | 1344 | 95 |
| 4*2AWG | 133 | / | 0.0223 | 60 | 170 | 1.41 | 1705 | 80 |
| 5*2AWG | 133 | / | 0.0223 | 60 | 170 | 1.41 | 1853 | 80 |
UL Certificate for SOOW CORDS, XHHW,SER,SEU,MC Cable
COMPANY INFORMATIONHebei Huatong Wires and Cables Group Co., Ltd.It was established in 1993.
Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billionYuan.Now there are more than 1000 employers in our company, among which more than 150 are technicians.TWO FACTORIES IN CHINA ! ONE FACTORY IN Tanzania!
Yearly Export Amount 200Millon
Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects.
We are top cable manufacture of rubber serious cables . Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC power cables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We are OEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
Certificates and"National Industrial Production License", "Certificate of Recommended Enterprises and Products for National Grid", "Adopting International Standard Certificate", and "High-Tech Enterprise Certificate", "Certificate of High Quality Products", "Certificate of Scientific and Technological Achievements", "Qualified Supplier Certificate", "China Classification Society Certificate of Works Approval", "Det Norske Veritas Type Approval Certificate", "Railway Product Certificate", "Safety Certificate of Approval for Mining Products", "National Mandatory Product Certification", "Certificate for China Compulsary Products Certification" and "Practical New-Type Patent Certificate".Package Picture
1.24years production experience and 15 years export experience .
2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc
3.OEM service available based on official & legal authorization.
4.Strict quality control system.
5.Rapid delivery and feedback Faster lead time than our competitors.
6.Excellent quality with reasonable price.
7. Strong technical support (technical data, drawing, etc.)
8.Professional teamwork service for you actively.
9.Stock available, Free sample is available.
