W Shape Mosi2 Heating Elements

Name: W Shape Mosi2 Heating Elements
Brand: all-electronics-online.com
SKU: 678381792
Availability: InStock
Rating: 4.9 (22 reviews)

Price:	US $ 20-380/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	6/Piece
Pay Type:	T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	W shape
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Grade:	1800/1700
Dia:	3/6, 4/9, 6/12, 9/18, 12/24mm etc.
Structure Material:	Non-Metallic Material
Application:	High Temperature Furnace

Product Description

MoSi2 heating element:
Molybdenum disilicide(MoSi2) heating elements for element temperatures up to 1800C(3270F), Our MoSi2 heating elements are available as straight or bent elements in a wide range of shapes and sizes, All characterized by long life and consistant perfomance.

1. Specification:
Type: 1800C/1700C
Dia: 3/6, 4/9, 6/12, 9/18, 12/24mm etc.
Type: I, U, W,and UL, Spiral,Muti U shape, etc
And we can produce according to your requests.

2.Physics Characters:

Volume Density	Bending Strength	Vickers Hardness	Porosity	Water absorption	Heating Elongation Rate
5.5g/cm3	15-25 kg/cm3	(HV)570kg/mm2	7.4%	1.2%	4%

3. Chemistry Character
MoSi2 heating element is used in the high temperature under oxidizing atmosphere. It will form the SiO2 film which can keep the element from being melted. During the oxidizing process, the SiO2 protecting film is formed again when the element continues to be used. The MoSi2 heating element must not be used in the temperature between 400C and 700C for a long time, otherwise the element will be cremated under the strong oxidizing function in the low temperature.

We provide special designed MoSi2 elements according to customer needs, enabling an optimized element design for each particular application.
