Xm18-3008pmu 4-20mA Linear Proximity Sensor

Name: Xm18-3008pmu 4-20mA Linear Proximity Sensor
Brand: all-electronics-online.com
SKU: 825548725
Availability: InStock
Rating: 4.5 (127 reviews)

Price:	US $ 4.99/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	XM18-3008PMU
Type:	Infrared Sensor Switch
Principle:	Infrared
Wires:	PNP (',Three-Wires)
Standard:	Standard
Application:	Basement
Size:	120 Type
Certification:	CE

Product Description

Kampa LM12-3004NA inductive proximity sensor

A. SPECITICATION of proximity sensor :

MODEL:		XM18-3008PMU
Non-flush	Detection distance	8mm
	Input: DC6-36V Output: PNP NO, 4-20ma
Output voltage drop DC/AC			DC<3V AC<10mA
Consumption current			DC<15mA AC<10mA
Standard detected object			15151(A3 Iron)
Repeat precision			0.02
DC/AC Response frequency			300HZ/25HZ
Working environment temperature			below 25°C to 75°C
Insulation resistance			≥50MΩ
Shell meterial			Metal
Protection grade			IEC standard IP67

1. Switch category(LM: inductance type; CM: capactitance type;SM:Hall type; AM:safety explosion-proof type; XM: mimic linear type)

2. Outward appearance code(C: Cylinder type; F: Angular column type and planeinstallation type)

3. Operating voltage(30: 6-36VDC; 310: 5-24VDC; 320: 12-60VDC; 20:90-250VAC; 210: 24-250VAC;220: 380VAC; 40: 12-240VDC/24-240AC; 50: Special voltage)

4. Detection distance( 01: 1mm; 05:5mm; 10:10mm)

5. Output method (N: Three-line DC NPN output;P: Three-line DC PNP output)

6. Output status(A: NO; B: NC; C: NO+NC; MU: Mimic voltage; MI: Mimic current)

7. Auxi function code(T: With connector; Y: Water proof, oil proof; I: Special requirement)
