Xr04cx-5n0c1 Dixell Temperature Controller for Red Display

Name: Xr04cx-5n0c1 Dixell Temperature Controller for Red Display
Brand: all-electronics-online.com
SKU: 759685925
Availability: InStock
Rating: 4.9 (113 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	20/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	XR04CX-5N0C1
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Internal:	External
Usage:	Air Conditioner, Refrigerator
Control Type:	Digital
Type:	Temperature Controller
Control Method:	Electronic Type
Operating Principle:	Compression Refrigeration Equipment
Cooling Purpose:	Cold Storage
Material:	Plastic

Product Description

dixell temperature controller

1.Innovative digital controllers dedicated to heat and M.T.-L.T. refrigeration

2.Easy and intuitive programming mode

3.Display with icons and integrated measurement units

4,On/off key

5.Plastic front frame with "cut out" "WING" compatible

6.Up to 2 light switches

7.Energy saving cycles through digital input

8.Fast freezing with dedicated set point

9.Regulation stop through auxiliary probe

10.Regulation restart with door open alarm

11.Temperature or HACCP Max and Min function

12.Configurable digital input also as probe

Main technical parameters of Dixell electronic controller

FEATURES	XR20CX	XR30CX	XR40CX	XR60CX
Display:n°digits Power supply	±3d.p. 12,24Vac/dc 24,110,230Vac 9÷40Vac*	±3d.p. 12,24Vac/dc 24,110,230Vac 9÷40Vac*	±3d.p. 12,24Vac/dc 24,110,230Vac 9÷40Vac*	±3d.p. 12,24Vac/dc 24,110,230Vac 9÷40Vac*	±3d.p. 12,24Vac/dc
Probe inputs
Thermostat Thermostat2 Defrost Defrost2 Condenser	NTC/PTC NTC/PTC On HOT KEY	NTC/PTC NTC/PTC On HOT KEY	NTC/PTC NTC/PTC NTC/PTC On HOT KEY	NTC/PTC NTC/PTC NTC/PTC On HOT KEY	NTC/PTC NTC/PTC NTC/PTC On HOT KEY
Digital inputs
Alarm,start defrost,AUX Door switch,pressure switch,probe Alarm,start defrost,AUX Door switch, pressure switch	config	config	config	config	config
Relay outputs
Computer Computer2 Thermostst2 Defrost Defrost2 Fans Light or alarm Anti-sweat	8A,20A opt	8A,20A opt 8A	8A,20A opt 8A	8A,16A opt 8A 8A	20A 8A 8A
Other
Hot Key/Prog Tool Kit output Remote display output Serial output Buzzer Real time clock	Pres X-REP opt TTL opt	Pres X-REP opt TTL opt	Pres X-REP opt TTL opt	Pres X-REP opt TTL opt	Pres X-REP opt TTL opt

XR20CX : Digital Dixell controller for N.T. with "off cycle" defrost

XR30CX: Digital Dixell controller for N.T. with "off cycle" defrost and additional configurable reply

XR40CX: Digital Dixell controller for M.T. and L.T. with electrical or hot gas defrost

XR60CX: Digital Dixell controller for M.T. and L.T. ventilated application with dual humidity function

13.Virtual probe management

14.Conderser temperature management to prevent critical plant situations

15.Hot key connector for a quick and easy programming

16.Serial line connection to monitoring systems

17.Connection for X-REP remote display(alternative to TTL output)

18.3VA max power absoraption

19.Display with red LED(10,5mm high) and icons
