100g 16 Channels DWDM Mux/Demux Module

Name: 100g 16 Channels DWDM Mux/Demux Module
Brand: all-electronics-online.com
SKU: 837118155
Availability: InStock
Rating: 4.7 (98 reviews)

Price:	US $ 200-450/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

100G 16 Channels DWDM Mux/Demux module

Features

Low Insertion Loss
High Channel Isolation
Excellent thermal stability
High Stability and reliability
Telcordia compliant
RoHS compliant

Applications

DWDM systems
Metro/Access optical network
Single direction / Bi-direction

Specification

Parameter	Unit	Specification
Channel Center Wavelength	nm	C/L band, ITU-T grid
Channel Spacing	nm	0.8(100GHz)			1.6(200GHz)
Channel Clear Passband	Nm	ITU±0.11			ITU±0.25
Power Monitor Rate	%	1			1
Insersion Loss For Monitoring Port	dB	≥20 and ≤24			≥20 and ≤24
Number Of Channels	NA	16			16
		Min		Max	Min		Max
Channel Insertion Loss(without connector)	dB		4.0			4.0
Passband Ripple	dB		0.5			0.5
Adjacent channel Isolation	dB		28			30
Non-adjacent channel Isolation	dB		40			40
Return Loss (without connector)	dB		45			45
Directivity	dB		45			45
Polarization Dependent Loss	dB		0.15			0.15
Polarization Mode dispersion	dB		0.1			0.1
Operating Temperature	ºC	0 ~ 70
Storage Temperature	ºC	-40 ~ 85
Maximum Power Handing	mW	300

Ordering Information
a. Chassis

4-slot, 19'' 1RU Chassis

b. Plug-in Module

PN: DWDM-X1-X2-X3-X4-X5-X6

X1	X2	X3	X4	X5	X6
Channel pacing	Channel number	Starting wavelength	Connector type	01	Application type
100: 100GHz 200: 200GHz	8:8 channels 16:16 channels	21:ITU ch-21nm 22:ITU ch-22nm	FC/LC/SC/UPC, APC	Power monitor port at 1%	D: Demux M: Mux M/D: Mux & Demux

Prod Model:	DWDM-100-16-21-LC-01-MD
Usage:	DWDM Systems, Metro/Access Optical Network
Type:	Wireless
Support Network:	Ethernet
Information Content:	Data
Certification:	GS
Condition:	New

Shenzhen Link-all Technology Ltd (manufacturer) was founded in 2012, and we have been endeavored in research and development, production and sale of passive optical components and modules, all kinds of transceivers, PLC Splitters, broadband access products and so on.

The predecessor of our company Unisky Creacom Technology Co., Ltd (Trading company ) was founded in 2006, Since then, we've provided to major Telecomm Operators of Hong Kong, Macao and Singapore with multiple communication products and solutions, The outstanding features and advantage are professional and excellent sales team, efficient and orderly management, competitive price, extensive superior sales channels, as well as high standard quality and flexible prices

Over the years we have gained extensive technical expertise as well as practical experience in the field of optic communication products. Link-all is committed to product design, research and development, manufacturing, service support for global data center, cloud computing, TV broadcasting network, metro network, broadband access network and so on.

Up to now, Link-all's products have been shipped to over 60 countries including USA, Europe, South America, Asia, Arica and other regions as well, we also have offered OEM and ODM custom design services to customers now, welcome any inquiries. Join us today, let's shake hands and create double wind world.
