19mm Red Emergency Stop Switch

Name: 19mm Red Emergency Stop Switch
Brand: all-electronics-online.com
SKU: 682846011
Availability: InStock
Rating: 4.9 (25 reviews)

Price:	US $ 3.9-5.1/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

19mm waterproof emergency switch push button

Product Category:

Hot Products:

Packging Details:

We pack 40 pieces diameter 19mm metal push button switches into 1 foam box to protect them. We supply 40 pieces rubber rings and 1 piece guarantee card with these switches. Then we packed this foam box into a plastic bag, it will packed into a small box with 3 layers corrugated. Finally, we packed 10boxes / 20 boxes into A 5 layers corrugated export carton.

About Us:

Yueqing Dahe Electric Co., Ltd is a professional manufacturer of push button
Switch, signal lamp, buzzers, waterproof and anti vandal metal push button switch for more than 10 years with CE and RoHS certificates.

Our products are widely used in machinery, machine tools, electric power,
Electronics, production control, medical, banks, ships, automation and other
Industries.

We can customize push button switch according to your specification, If you have any requirement or question, please feel free to contact us.

We offer a warranty on all items that we sold. Item will be tested before ship,it will be in good condition,if there are some problems with the item,feel free to contact us. send the photo to us that we can check and give you best solution .

Tel: 0086-577-62708000 Fax: 0086-577-62708007

PRODUCT SPECIFICATION

Item No.		HBS1AGQ-11TS
Specification		1NO1NC MOMNTARY
Terminal Type		PIN TERNIMAL
Switch Type		C(SNGLE BREAKPOINT FAST-MOTION CANGEOVR CONTACT)
Switch Specification		Ith:5A Ui: 250VAC
Contact Resistance		≤50m Ω
Insulation Resistance		≥1000MΩ
Dielectric Strength		2000V AC
Operating Temperature		-20degree~+55degree
Machanical Life		>2,000,000 times
Electrical Life		>50,000 times
Panel Thickness		1~10mm
Torque		5~14Nm
Operating Pressure		About 4N
Operating Stroke		About 2.5mm
Protection Degree		IP67,IK09
Material	Contact	Sliver Alloy
	Button	alluminum
	Case	alluminum
	Base	PBT

FAQ:

Why choose us?

1:complete product catagory,metal push button switch,plastic bush button switch,signal light,rotary switch,key lock switch,emergency stop switch,buzzer and so on.

2:13 years manufacturing experiences

3:factory direct price

4safe payment terms:T/T,PAYPAL,WEST UNION

5:OEM avaliable

6 provideing customized prodects

7 having certificate of CCC,CE,ROHS,UL,TUV,SGS,ISO9001

Prod Model:	HBS1-AGQ-11TS
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Item No.:	Hbs1-Agq-11ts
Switch Rating:	5A/250VAC
The Front Shape:	Mushroom
The Crust Material:	Alluminum
Protection Degree:	IP65,Ik09
Operation Type:	Latching
Size:	19mm
Terminal Type:	Pin Terminal
Contact Material:	Silver Alloy
Certificate:	CCC,Ce,RoHS,SGS,UL,TUV,ISO9001
Type:	Composite
Usage:	Check Button
Kind:	Double-pole on-off Switch
Brand:	Hban
Certification:	ISO9001,Ce,RoHS,CCC

Yueqing Dahe Electric Co., Ltd. Set up on 2003, is a professional manufacturer of push button switch, indicator lights, signal lamp, buzzers, high-intensity resistance and anti-vandal metal push button switch.

Our products are widely used in machinery, machine tools, electric power, electronics, production control, medical, banks, ships, automation and other industries. We have state-of-the-art production, laboratory equipment and testing apparatus, and insist on the quality of survival, to serve and promote the development quality management service support system, to ensure that the product of the index is quality controlled state.

After years of pioneering spirit, the company has now made a number of patents, the products have passed national mandatory CCC certification, CE certification and RoHS certification, with high quality and cost-effective, favored by the majority of users. We sincerely welcome people to join together to create brilliant.

At present, we cooperate with customers in more than 50 countries and areas. We sincerley hope to cooperate with you. Welcome to become our Distributor in your city.

Tel: 0086-577-62708000 Fax: 0086-577-62708007
