22mm Power Symbol Selflock Push Button Switch

Name: 22mm Power Symbol Selflock Push Button Switch
Brand: all-electronics-online.com
SKU: 762101555
Availability: InStock
Rating: 4.8 (76 reviews)

Price:	US $ 1-1.5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	100/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Mounting Hole Size:Φ22mm
Switch Rating :5A / 250VAC
Front Shape:Flat
Connector:Pin terminal
Operation type:1NO1NC
Illuminated type : Dot- illuminated
Protection Degree:IP65,IK08

Packing details:

We pack 20 pieces diameter 22mm metal push button switches into 1 foam box to protect them .We supply 20 pieces rubber rings and 1 piece guarantee card with these switches.Then we packed this foam box into a kraft paper box,25boxes will be packed into a carton.

Item NO.		HBGQ22-11D/S	HBGQ22-11DZ/S
Specification		1NO1NC,Momentary	1NO1NC,Latching
Front Head Shape		Flat Round
Terminal Type		Pin terminal(2.8*0.5mm)
Switch Type		C Single breakpoint snap-action changeover contacts
Switch Specification		Ith:5 A Ui:250V AC
Contact Resistance		≤ 50mΩ
Insulation Resistance		≥1000mΩ
Dielectric Strength		2000V
Operating Temperature		-22 degree~+55 degree
Machanical Life		>1,000,000times
Electrical Life		>50,000times
Panel Thickness		1-10mm
Torque		5-14Nm
Operating Pressure		3~5N
Protection Degree		about 3.1mm
Materisl	Contact	IP65,IK08
	Button	Silver Alloy
	Case	Stainless Steel
	Base	Stainless Steel

5.Why choose our switches

1) We can provide you with different types of micro switches for your selection.

2) We can offer good quality electric life 500, 000-1, 000, 000times.

3) Various operating force, height and color for one switch for your choice.

4) Safety, on-time delivery, excellent quality with competitive price.

5) ODM&OEM professional design.
7.CUSTOMER'S QUESTIONS
Q1:How about the delivery time?
Answer:It's depends on the quantity, for example, 10000PCS need to OEM,
delivery time is 3-7 days.

Q2:What quality you can offer to us?
Answer:We now can do 1/2 years warranty, during the warranty time we can exchange all defective products from customers for free.

Q3:Can you give me samples to test?
Answer:Yes

Q4:What's you MOQ?
Answer:MOQ 2500PCS, mixed order acceptable, welcome trial order.

Q5:What's the delivery term?
Answer:Both EXW and FOB Ningbo are acceptable.

Q6:What's the payment term?
We could start our discussion about payment term from second order on.

Q7:What's the shipment way?
Answer:Express:DHL, UPS, FedEx, TNT and SF express.
Forwarder:Air shipment or sea shipment.

Prod Model:	M2B
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Switch Rating:	5A/250V AC
Contact Configuration:	1no1nc
Operatiion Type:	Momentary/Latching
Crust Material:	Stainless Steel
IP Protection Degreee:	IP65,Ik08
Illuminated Type:	DOT-Illuminated
Type:	Normal Open
Usage:	Check Button
Kind:	Single-pole on-off Switch
Contact Type:	1nc1no
Brand:	Chnanma

Yueqing Nanma Electrical Co., Ltd.and Jiangxi Nanma Electrical Co, Ltd Which a professional R&D and manufacture Micro switch, limit switch, travel swith, sealed switch, waterproof switch, toggle switches and so on Our company was established in 2004. Our ISO 9001-certified factory occupy a total land area of 1000 square meters and house more than 200 employees and two production lines outfitted with advanced production equipment. We have a monthly outup of 10 thousand sets of switch, which are exported to the Southeast Asia, Middle East, European. The market feedback shows that the products may completely substitude for the similar, work force: Our 2 QC auditors ensure all our products passed CE and CCC certifications. Implementing strict quality control in the whole production process, We have 2 R&D personnel with more than five years of experience who can design as customer offered sample to open model. We have 4 trade representatives with more than three years of experoence who are proficient in English. We are sincerely invite you to witness our development and resplendence together! Contact us today.
