Air Cooler Motors Polypropylene Capacitor Cbb60 Manufactory

Name: Air Cooler Motors Polypropylene Capacitor Cbb60 Manufactory
Brand: all-electronics-online.com
SKU: 734492182
Availability: InStock
Rating: 4.8 (31 reviews)

Price:	US $ 0.25/Piece
Min Order:	10000/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

SINOCAPS #CBB60 AC Motor run capacitor with good self-healing characteristics, long-life span and high proportionality, its widely used as the start-up and running capacitor, which is especially for the electric fan.

Capacitance Range	1μF~150μF
Rated Voltage	250VAC~500VAC(50/60Hz)
Capacitance Tolerance	±5% or Fulfilled upon request
Loss Tangent	Tgδ≤0.002(50Hz-100Hz)
Standard Temperature	-25ºC~+70ºC,-40ºC~+85ºC
Climate Class	25/70/21, 40/85/21
Test Voltage	Between terminals	AC≥2.00Un 2S NO BREAKDOWN
	Between terminals and case	AC≥2000V 2S NO BREAKDOWN
Insulation Resistance	Between terminals	Rj·C≥3000MΩ.μF
	Between terminals and case	Rj≥1000 MΩ.μF
Security Level	P0, P1, P2
Executing Standard	GB/T3667.1-2005, IEC60252-1:2001, IEC252

SINOCAPS' AC Motor capacitor features:

1. Non induction winding structure of metallic polypropylene membrane.

2. Small volume, light weight, low loss, excellent self-healing characteristic.

3. Non-toxic and non-leaking, profit environmental protection.

SINOCAPS' AC Motor capacitor product description:

1. Use square plastic shell, and insulation sealed lid for sealing plastic lid for sealing or resin for sealing.

2. Copper soldering terminal, plastic coated copper wire and CP wire are available.

3. With frequency 50/60Hz, voltage 250Vac, and can help motor start and run.

4. It can continuously operate under rated conditions.

SINOCAPS' Strength:

High Quality

1. Exported to more than 60 countries: England, Russia, Bangladesh, Argentina, Poland and so on.

2. More than 90% customers make payment before meeting us.

3. Reorder rate up to 88%.

4. Never sell any renewed capacitor.

5. Focusing on middle and high-end market, we never seize market by using inferior material.

6. We are more than 8 years of professional production of capacitors.

Full Service

1. 3000hours warranty

2. R&D, OEM, ODM

3.Sourcing service as long as you give us the picture and specifications

4. Quick response within 2-8 hours, solve problems in 2 days.

5. Visit our factory anytime, 24-hours phone call is available, ship all samples within 2-10 days.

Reasonable Price

1. With ourselves factory, no more mark up and resale price.

2. Aim at long-term cooperation, always offer our best price and best solution to you.

Prod Model:	CBB60
Type:	Polypropylene Capacitor
Application:	Automobile
Package Type:	Through Hole
Capacitance:	1-150UF
