| Prod Model: |
LLT-DS-VER7.7.1 |
| Device Type: |
Video Interface |
| Suitable Model: |
Ds3 |
| Android Version: |
4.4 5.1 |
| Map: |
Google Map / Igo |
| Video Support: |
HD 1080P |
| WiFi / Bluetooth: |
Yes |
| Definition: |
480*800 |
| Hardware: |
1.6 GHz 4 Core Chip 1 / 2 GB RAM 16GB ROM |
| Model: |
Llt-Ds-Ver7.7.1 |
| Brand: |
Lsailt |
Product Description
Android GPS navigation system box for Citroen DS3 DS4 DS5 DS6 SMEG+ MRN system video interface
Suitable car model: Citroen DS3 DS4 DS5 DS6 SMEG+ MRN system
Android's features:- Android 5.1 & 4.4 system, Quad core 1.6GHz Cortex-A9 chip, quickest running speed in market.
- Compatible all Android apps include YouTube, Waze, Google map, iGO, Real-time & offline navigation etc, free download from Play store.
- Compatible to car origin rear view & front view, DVR, 360 panorama, TV box, TPMS optional.
- Connect via Wi-Fi Bluetooth USB.
- Could be switch to origin system with just one click on dashboard or steering wheel.
- Simple plug & play installation.
- Multi languages are supported, include English русский Français Español Português Arabic Persian Japanese Korean Hebrew etc
Professional festures & hardware- Multi screen interactive display is supported, LVDS out put.
- Accessories like rear view, 360 bird eye camera box, DVD, DVB-T TV box, DVR, mirror link, video play via USB.
- Support 2 RGB & LVDS video signal input.
- HD 1080P video play supprted.
- Voice control navigation from both factory MIC or ours.
- Display definition 480*800.
- RK3188T/PX3 main processor, Quad core Cortex-A9 structure, much quicker than Allwinner T3 A7 model.
- WiFi module: RTL8188 / RTL8723.
- BT module: RTL8723BU, support BT4.0, firmware support Bluetooth functions.
- Touchscreen interface: Support 4-wire resistive touch layer
Custom Properties| Way to Install | Original Car Screen Installation | Advantage | Retains All Features |
| RGB IN | Support | AV IN | AV1 or AV2 |
| DVR IN | Support | Rear View | Support |
| CPU | 1.2GHZ-1.6GHZ | RAM | 1GB 2GB |
| Flash | 16GB | HD Video | 720P/1080P |
| Working voltage | 9-12V | OS | Android 4.4 5.1 |
| HVGA | 800X480 | MAP | GOOGLE MAP/IGO |
| Play Store | Support | Voice | Support |
| WIFI | Support | Specific Features | One-Key Reset |
| Product Accessories |
| Host Interface | 1(standard configuration) |
| Host Android | 1(standard configuration) |
| LVDS IN | 1(standard configuration) |
| LVDS OUT | 1(standard configuration) |
| AV IN/OUT | 1(standard configuration) |
| POWER Line | 1(standard configuration) |
| ANT | 1(standard configuration) |
| Specification | 1(standard configuration) |
| Warranty card | 1(standard configuration) |
| Microphone | 1(standard configuration) |
| SPK | 1(standard configuration) |
| Map card | 1(standard configuration) |
Please add me on (+86-136 9976 5242 Cosmo) for directly contact!
Quality warranty policy:3 month free replacement and 1 year free maintenance.Deliver 1 or 2 days after payment received.
