Best Sales Insulating Varnish Enameled Aluminum Wire for Motor Winding

SZ CABLE mainly supply:

1-Enameled Wire( CCA wire, Al. wire, Copper wire)
2-Electric wire( CCA wire, Al. wire, Copper wire)
3-Electric cable( CCA wire, Al. wire, Copper wire)
4-Bare/tinned conductor wire( CCA wire, Al.-alloy wire, Copper wire)
5-Enameling machine(size from 0.02-8.00mm wire)


Advantages of aluminum wire:
Due to much lower density than copper clad aluminum wire, weight per unit product can save at least 60% than the copper wire. Using aluminium wire will save much more cost of production materials.

Disadvantages of aluminum wire:
Tensile strength is about 30%-40% of the copper wire, the conductor is easy to stretch during production; The surface of the aluminum conductor is not easy to direct solder, special treatment of welding joints is required.

Specifications
Polyamide-imide enamelled aluminum wire
Conductor:aluminum
Diameter: 0.11-8.00mm round enameled aluminum wire
Standard: IEC, NEMA, GB,JIS
Thermal Class: 200,220 centigrade
Enamelled types : EI/AIW,QZY/XY
Certification:UL Approved, iso9001, iso14001,RoHS,REACH

Product details:

Product Features:
High breakdown voltage
Good adhesion
Few pinhole
Sustained and stable quality


Main Applications :
All kinds of household electric motors, vacuum cleaner motor, electric motor
All kinds of transformers, inductors, rectifiers
Fan motor


Product application Description
For Polyamide-imide enamelled aluminum wire
Its thermal class 200,220 degree.
The product is of high heat resistance, also has resistance to refrigerants, cold resistant, radiation resistant properties, high mechanical strength, electrical properties and is of stable resistance chemical properties and good resistance to refrigerants, strong overload capacity. Wire is widely used in refrigerator compressor, air conditioning compressor, electric tools, explosion-proof motor and high temperature, cold, radiation, overload, etc.

Product Pictures:




Company Information:
Suzhou Wujiang Shenzhou Bimetallic Cable Co., Ltd. parent company is located in Qidu Town,which is well known as the cable capital in China. Our company was set up in 2005, and now is the largest enameled copper clad aluminum wire production enterprise. The main products are enameled copper clad aluminum wire, enameled aluminum wire and copper clad aluminum wire. Enameled wire specifications include polyurethane (QA/UEW), (130,155,180) polyester QZ/PEW, class 180 polyester imide QZY/EIW, 200 grade polyamide-imide compound polyester imide QZY/XY/EI/AIW. At present, we are supplying size from 0.100 mm - 4.60 mm. Products are widely used in various types of electronics, (air conditioners, refrigerators, washing machines, electric tools) motor, large, medium and small transformer, electromagnetic induction coil, the motor of the car, charger, ballast, relays, etc. products. Strict quality control and long-term stable supply of products is the cornerstone of SHENZHOU's long-term stable development.

Certificate:
Standard: IEC, NEMA, GB,JIS
Thermal Class: 130/155/180/200/220 centigrade

Enamelled types : UEW,PEW,EIW,EI/AIW,AIW
Certification:UL Approved, iso9001, iso14001,RoHS,REACH

FAQ:
1. Q: Are you a factory or trading company?
A: We are a factory.

2. Q: What certificate do you have?
A: We have ISO9001,14001,SGS,REACH and UL certificate.

3. Q: How does your factory do regarding quality control?
A: We have a special QC department with 15 inspection personnel. Quality inspection team including incoming material, process and finished product inspection

4. Q: How large the scale of your company?
A: Our Company covers almost 40,000 square meters, Including 8 standard factory buildings.

5. Q: What's the main market of your company?
A: We have customers all over the world.

6. Q: What's your company 's product scope?
A: We have many kinds of products ,such as enameling machine, copper clad aluminum wire, enameled aluminum wire, enameled copper wire, enameled copper clad aluminum wire, copper rod, power wire and cable, communication cables.

7. Q: What's your company 's product scope?
A: We have many kinds of products ,such as enameling machine, copper clad aluminum wire, enameled aluminum wire, enameled copper wire, enameled copper clad aluminum wire, copper rod, power wire and cable, communication cables.

8. Q: Where is your factory located? How can we visit there?
A: Our factory is located in Wujiang Dis. SuzhouCity, Jiangsu Province, China,
Near Shanghai Hongqiao Airport(90kms). We offer transportation service
