Current-Limiting Fuses Type W for Motor Protection

Name: Current-Limiting Fuses Type W for Motor Protection
Brand: all-electronics-online.com
SKU: 737627135
Availability: InStock
Rating: 4.7 (62 reviews)

Price:	US $ 4.6/Piece
Trade Terms:	FOB,CFR,EXW
Min Order:	3/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	WDF. O, WKF. O
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Rated Voltage 3.6~10kv:	Rated Current up to 400A&224A
Color: Brown, White:	Material: Porcelain
Length: 254, 403, 600mm:	Diameter: 51, 76mm
Breaking Capacity:	High
Standard:	GB15166.2,IEC282-1,Bs
Shape:	Tube
Type:	High Voltage Current-Limiting Fuse
Fusing Device:	Striker
Usaga:	High Voltage Electrical Equipment

Product Description

Key Specifications/Special Features:

1. Motor protection

2. High breaking capability

3. High voltage current limiting fuse

4. Suitable for electrical power system of AC 50Hz, rated voltage 10kV and below, rated current up to 400A(3.6KV), 224A(7.2KV) circuit for protecting motor and other power equipment from overload and short-circuit.

5. High-pressured fuse conforms to the national GB15166.2 standard and the international electrical committee IEC 60282 standard as well as German DIN standard and British BS standard.

Wenzhou Shuguang Fuse Co., Ltd is a manufacturer of electric appliances with well-equipped testing equipment and strong technical force.

With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in electrical industry and other industries.

Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.

We welcome new and old customers from all over world to contact us for future business relationships and achieving mutual success!
