Definite Purpose AC Contactor 1 Pole 30A 24V/120V/240V Electrical Contactor
Specifications:| FLA | Locked Rotor Amps | Non Inductive Amps | Poles |
| 240V | 277V | 480V | 600V |
| 20 | 120 | 110 | 100 | 80 | 25 | 1 |
| 25 | 150 | 150 | 100 | 80 | 35 | 1 |
| 30 | 180 | 180 | 150 | 120 | 40 | 1 |
| 35 | 180 | 180 | 150 | 120 | 50 | 1 |
| 40 | 240 | 240 | 200 | 160 | 55 | 1 |
| Electrical Contact Ratings:20A-90A electrical coil ratings:24-600V life rating,100,000&250,000 cycle options. |
| Options:1,2,3,4 pole fits 24,120,240 and 480 VAC coils wide range of electrical ratings screw, box or pressure plate connections NEMA mounting base. NO/NC end switch kits. |
| Applications:Commonly used for Refrigeration, Air Conditioning and Heating. Also fits for Food service equipment, Vending machines, Compressors,Pumps, Cranes, Hoists,Welding machines,Power supplies,Lighting etc. |
| Replaces:Siemens/45EG10AJA, Fasco/C1S30A, Hartland Controls/HCCY1NQ02AA303,Hartland Controls/HCCY1XQ02AA303 |
Advantages:High arc-resistant phenolic resin material hold stationary terminals,positions actuator, and magnet/coil assembly.It has much stronger endurance and insulating ability than normal contactors .
The internal construction of the HCDP series is manufactured from engineered compounds to provide excellent mechanical life in the most demanding applications.
Premium Silver Alloy contacts designed for long lifeShock-resistant actuator arms provide mechanical durability Durable Molded Plastic Housing Industry standard mounting plates Compact Design, easy to install .Features:Meets The ARI 780/790 Standard
Universal metal mounting plate allows for complete ease of replacement
Long electrical life; tested to 250,000 cycles
Reliable mechanical life; tested to 1,000,000 cycles
EE magnet assembly assures optimal performance without sacrificing power consumption
Superior copper coil
Performance unaffected by mounting position
Flexible termination options suitable for various applications
Dust-free internal constructions
