F Type Meet DIN41612 Standard Rectangular Connectors

Name: F Type Meet DIN41612 Standard Rectangular Connectors
Brand: all-electronics-online.com
SKU: 121332
Availability: InStock
Rating: 4.9 (86 reviews)

Price:	US $ 4.5-5/Piece
Trade Terms:	FOB,EXW
Min Order:	5/Piece
Pay Type:	T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	F Series
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Size:	F48-Ms
Size1:	F48-Fs
Size2:	F48-Fsl
Size3:	F48-Msl
Size4:	F48-Fw
Size5:	F48-Fwl
Size6:	F48-Myl
Size7:	F32
Type:	Socket Terminals
Material:	Copper
Application:	Transmission of Electrical Signals
Certification:	CE
Brand:	Kaipu

Product Description

F series rectangular connectors incorporate the lasest design features and provide the assurance of high quality and reliability. It's technical characteristics and dimensional drawings meet the requirements of iec603-f and din41612. The type of terminations include wrap, solder, cable, crimp. They have a wide range of application and interchangeable with connectors of foreign brand in the same category. We can match your special requirement by changing the number of contacts and the type of termination.

Products ordering

                F /   48 /-- M / S / L
                  1 / 2 / 3 / 4 / 5
    1.Name of product:   F series
    2.Number of contacts :    32,48
    3. M-male connector,F-female connector
4.S-solder,W-wrap,Y-solder lugs
5. L-with cable,without L-without cable

Technical characteristics

Temperature	Relative humidity	Atmosphere	Vibration	Shock
-55°C~ +125°C	(90~95)% at40+2°C	101KPa~6.7Pa	5~500Hz 100m/s²	10~40strokes/min 250m/s²

Current	Voltage	Contact resistance	Endurabce
4A	300V	≤8mΩ	500 cycles

Environment	Voltage proof	Insulation resistance
Normal	2000V	≥1000MΩ
High temperature	500V	≥500MΩ
Moisture	500V	≥50MΩ
Low pressure	200V	-

Electronics supplier, China factory, connector manufacturer, plug supplier, Hangzhou Kaipu Electronic Technique Co., Ltd. is a company specializing in manufacture of circular connectors and rectangular connectors of high quality. We design and make water proof connectors, power plugs, electrical connectors.

ISO9001: 2008, Registration Number: 04005Q11376R0S.

Our products of connectors:

1. Circular series AISG, Y2, Y2M, Y3, Y4, Y4M, Y5, Y5A, Y11, Y27, Y50E(MIL-C-26482), PTB, YP21, YP28, YP36, YP50, JL5, JL16, JL33, FQ(IP67), FQ14, FQ18, FQ24, FQ30, FX16, FQN14, FQN18, FQN24,

FQN, FQC, FQX(IP68), kp11(IP67), kp22(IP68), KP32(C16), P20, P28, P32, P36, P40, P48, P55, P60, YD20, YD28, YD32, YD40, YD48, YD55, X, Q14, Q18, Q24, Q30, TY20, TY32, TY48, LYP, XC (similar as MIL-38999), 2PM, 2CX, CX, PC-4TB, PC-7TB, PC-10TB, PC-19TB, PC-32TB, PC etc.

2. Rectangular connector series B, C, F etc meet DIN41612, J7, J7A, J14A, J14B, J14D, J15, J36A.

Our connectors of KP32, FS1, FS2 have UL certificate: E308558.

Most of our connectors have CE certificates.
