High Efficiency Pure Sine Wave DC12V AC220V 1500W Power Inverter
| Price: |
US $ 153-155unit |
| Trade Terms: |
FOB,EXW |
| Min Order: |
10unit |
| Pay Type: |
T/T,Western Union,Money Gram |
High Efficiency Pure Sine Wave DC12V AC220V Power Inverter 1500w
1. Data
1.Product Introduction
1.high frequency pulse width modulation technology
2.excellent double-faced circuit board and components
3.high quality and high performance
4.protection function:
overload protection
over-current protection
high-temperature protection
short-circuit protection
battery reverse connection protection
battery high-voltage and low-voltage protection
built-in fuse protection, etc
Product appliation
Portable Power for many power tools and various appliances,including vacuum cleaners, small refrigerators,TVs and more.Great for autos, trucks, RVs,boats,camping and more!
2.Features
1) Compact and light weight
2) Modified sine wave output
3) High efficiency
4) Voltage overload protection
5) High output current surge
6) Low voltage alarm / shut down
7) Input and output fully isolation
8) Low power consumption
Using scope & function:
1. For use in cars,boats,trucks,trailers and mobile homes
Take the power inverter to portable and get power to run lamps, radios or TVs
2. In an emergency such as blackout, attach the power inverter to your car battery or portable battery and get power to run your appliances
3. Ultra-compact metal housing:Small and rugged:Stored easily in any tool box, briefcase or glove compartment
4. Integrated fuse protection:Protects your battery and power inverter from damage due to outlet overload
5. The inverter can automatically detect low battery voltage and shut down to preserve the battery
6. Overload protection:Shutdown and alarm(integrated fuse protection, protects the battery,and power inverter from damage due to outlet overload)
7. Output short:Output short-circuit protection
About our factoryDOXIN is a professional manufacture specialized in electronics and solar products.We produce electronics products more than 10 years .We have professional development team.We pursues to establish the culture of"quality first ,reputation best".
FAQ:
What is the difference between a modified sine and pure sine wave inverter?
Modified sine wave:The most common,general-use inverters available are of the"Modified Sine Wave"variety,usually available at more moderate pricing compared to pure sine wave models.Modified Sine Wave inverters are designed to have somewhat better characteristics than Square Wave inverters, while still being relatively inexpensive.Although designed emulate a Pure Sine Wave output, Modified Square Wave inverters do not offer the same perfect electrical output.As such, a negative by-product of modified output units is electrical noise, which can prevent these inverters from properly powering certain loads. For example, many TVs and stereos use power supplies incapable of eliminating common mode noise. As a result, powering such equipment with a Modified Square Wave may cause a"grain";or small amount of "snow"on your video picture,or"hum" on your sound system.Likewise, most appliances with timing devices,light dimmers,battery chargers, and variable speed devices may not work well,or indeed, may not work at all.
Pure Sine Wave: Pure Sine Wave inverters provide electrical power similar to the utility power you receive from the outlets in your home or office, which is highly reliable and does not produce electrical noise interference associated with the other types of inverters.With its"perfect"sine wave output, the power produced by the inverter fully assures that your sensitive loads will be correctly powered, with no interference. Some appliances which are likely to require Pure Sine Wave include computers, digital clocks, battery chargers, light dimmers,variable speed motors,and audio/visual equipment.If your application is an important video presentation at work,opera on your expensive sound system,surveillance video,a telecommunications application,any calibrated measuring equipment,or any other sensitive load,you must use a Pure Sine Wave inverter.| pure sine wave inverter |
| (DC12V/24V/36V/48V--AC110V/220V/230V/240V) |
| | Item No. | DX-150 | DX-300 | DX-500 | DX-800 | DX-1000 | DX-1500 | DX-2000 | DX-2500 | DX-3000 |
| * Max continuous power: | 150W | 300W | 500W | 800W | 1000W | 1500W | 2000W | 2500W | 3000W |
| * Peak Load Power Rate: | 400W | 600W | 1000W | 1600W | 2000W | 3000W | 4000W | 5000W | 6000W |
| * NO load current draw: | <0.4A |
| * Input DC voltage Range: | DC10-15V |
| * Output Voltage Range: | AC110/220V±5% |
| * Output Frequency Range: | 60/50Hz+/-3Hz |
| * Max Outer Temperature: | < 65 °C |
| * Max Power Efficiency: | > 85% |
| * High Voltage Cut Off: | >DC15V±1V |
| * Low Voltage Alarm: | DC 10.5±0.3V |
| * Low Voltage Cut Off: | DC10V±0.3V |
| * Overload&Short-circuit Protection | YES |
| * Input Voltage: | DC 12V |
| * THD: | ≤5% |
| * Cooling: | Fan |
| * Product Size(mm): | 167*95*55 | 175*150*70 | 270*150*70 | 370*150*70 | 370*150*70 | 370*150*70 | 435*150*90 | 430*155*130 | 460*170*120 |
| * Packing size | 49*46*47cm(40pcs/ctn) | 61*37.5*26cm (8pcs/ctn) | 49*46*47cm(6pcs/ctn) | 51*46*47cm (8pcs/ctn) |
| * N.W: | 0.55Kg | 1.11Kg | 1.65Kg | 2.15Kg | 2.15Kg | 3.4Kg | 3.4Kg | 3.85KG | 5.7KG |
| * G.W: | 0.75Kg | 1.25Kg | 2.2Kg | 3.35Kg | 3.35Kg | 4.3Kg | 4.3Kg | 4.8KG | 6.65KG |
| Prod Model: |
DXP1515 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Output Waveform: |
Pure Sine Wave |
| Rated Power: |
1500W |
| Surger Power: |
3000W |
| Output Frequency: |
50/60Hz |
| Housing Material: |
Aluminum Alloy |
| Max Outer Temperature: |
<65c |
| High Volt Cut Off: |
>15DC |
| Overheat Protection: |
Yes |
| Phase: |
Single |
Guangzhou Doxin Electronic Factory is a manufacturer specialized in automobile electronic products. Currently, we mainly produce Car Power Inverter, Solar charge controller, Battery charger, transformer, Power adapter, Mobile phone charger, car emblem badge, wheel center cap, tire valve cap, car wheel sticker, car logo keychain which was established at the beginning of 1998.
We utilize advanced encrypting technologies, full automatic production line, Multi function testing. With features of "high efficiency, detection function, intelligent and environmental protection and energy saving", Products meet EU RoHS Green Directives, and wildly used in Car, Home furnishing, Outdoor, Travel, Patrol, Fieldwork ect.
Our production base with the perfect size was built and the base passed ISO9001: 2000 quality system certification, CE certification, RoHS certification, LVD certification, ETL certification and E-MARK. Modern factories, outstanding management and advanced technology become the best guarantee of product quality. Our products are selling well in our country, Europe, the United States, Middle East, Southeast Asia and other area with unique and innovative design, low interference technology, high performance-price ratio, the best technology and excellent quality. With over 10 years of R & D and production experience, OEM service. Our company has become one of the famous power inverter manufacturers in China.
Our Company continued to expand into international markets, at the same time, efforts to develop the domestic market, "DOXIN" products have caused widespread concern in the industry through the domestic marketing system, such as dealer network, OEM market. Car owners comprehensive experience to DOXIN forefront automotive technology products, which bring them convenience and happiness, once again demonstrates the strength and determination of the Guangzhou DOXIN electronic factory.
Adhering to the business principle of "Achieve Mutual Benefits from Good Cooperation", our employees are looking forward to establishing business relationships with clients both in the domestic and the overseas markets.
