High Precision 50g Load Cell for Balance Scale (B704)

Name: High Precision 50g Load Cell for Balance Scale (B704)
Brand: all-electronics-online.com
SKU: 820648755
Availability: InStock
Rating: 4.3 (103 reviews)

Price:	US $ 18-20/Piece
Min Order:	2/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	B704
Capacity:	50g, 100g
Applications:	High Precision Weighing Scales, Balances
Pattern:	Single Point
Out-Wire:	5 Wires
Feature:	High Precision
Production Process:	Strain Gauge
Material:	Aluminum

Product Description

1. Name: 50g 100g high accuracy aluminum single Beam Load Cells
2. Material: Aluminum

3. Capacity: 50g and 100g
4. Accuracy: C3
l Made of aluminum alloy.
l High accuracy, high side load tolerance
l Easy to install, IP65 protection
l Mainly used for electronic scales, electronic balance, price computing scales and industrial weighing systems

Number	Specifications	Technique
1	Capacity	50g, 100g, 200g, 300g
2	Accuracy class	C3
3	Rated output	0.8~1.0mV/V
4	Zero balance	±0.05 mV/V
5	Non-linearity	0.010%F.S.
6	Hysteresis	0.010%F.S.
7	Repeatability	0.010%F.S.
8	Creep(30min)	0.0106%F.S.
9	Temp.effect on output	0.01%F.S./10ºC
10	Temp.effect on zero	0.015%F.S./10ºC
11	Input impedance	405±5Ω
12	Output impedance	350±3Ω
13	Insulation	≥5000MΩ/100VDC
14	Recommended excitation	5V
15	Maximum excitation	15V
16	Compensated temp range	-10~40ºC
17	Operation temp range	-10~50ºC
18	Safe overload	150%F.S.
19	Ultimate overload	300%F.S.
20	Cable size	350mm
21	Weight approx.	0.1kg
22	Material	aluminum alloy
23	IP Class	IP65
24	Max.platform size	200mm×200mm

This high precision weighing scale load cells is special for weighing scales like kitchen scales or jewelry scales or precision weighing balances.
www.bransensor.com

What you could get from Brans?

Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.

Why choose Brans?

Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.

We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.

Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.
