Description
Length of Hot runner heater within 20-3000mm is mainly used for hot runner mold or, as well as other precision heating system. Spring heating ring external using high quality Ni-Cr steel tube, the internal use of high purity magnesium oxide , high temperature resistance wire, and first-class manufacturing technology . The wire is after the annealed, with flexibility can be bent into an arc or circle heating. Its high working temperature, fast heating, uniform heating precision, long service life, can be automatically controlled area, high thermal conduction, while internal heating material damage, external can be reuses.
1.Hot runner heaters also know as cable heaters can be formed to a variety of shapes as required by its many application.
2.Frequenty though,coil heaters are configured as samll diameter,high performance nozzle heaters that are fully annealed.
3.Spring hot runner heates are use on injection molding machine nozzles and sprue bushings supplying bushings supplying 360 degree of heat with optional distributed wattage available.
4.Hot runner heaters are also used as cartridge heaters where irregular size bores are found.A straight,round cable heater can snake through a seal in packaging equipment installations.
| Heatingsection | 2.2x4.2mm3x3mm3.4x3.4mm3.5x3.5m4x4mm |
| HeatingcoilID | 10mm~38mm |
| Heatingringheight | 40mm~200mm |
| Voltage | 220V~380V |
| Wattages | 200W~3000W |
| Build-inthermocouplepower | WithorwithoutJ/Kthermocouple |
| Leadwire | 500/1000/1200/1500/2000mm |
1.Hot Runner & Bushings
2.Tube Extrusion
3.Pipe Forming
4.Hot Runner Mould
5.Plastic Injection Machine
6.Plastic Extruder Machine
pecification are widely applied in American market or make regular or flat coil heater for enail as request | Sectional area | 3X3,4.2X2.2,4X2,4X2.7,4X2.5 3.3 X 3.3 3.5 X 3.5 4 X 4,2.2X1.3 |
| Minimum ID | 8mm |
| Sheath Material | SS304,SS310 |
| Insulation Material | High Pure MgO |
| Resistance Wire | Cr20Ni80 |
| Maximum Sheath Temperature | 700°C |
| Die Electrical Strength | 800V A/C |
| Insulation | >5 M W |
| Dimensional Tolerance | Coil I.D+0.1 to 0.2mm//Coil Length+1mm |
| Wattage Tolerance | +10% (+5% Available Upon Request) |
| Voltage | 12V~380V |
| Wattage | 70W~1000W |
| Build-inthermocouplepower | withoutor with J/Kthermocouple |
| Sheath's length | 500/1000/1200/1500/2000mm |
| Availablesheath | nylon,metal braided,fiberglass ,silicone rubber, kevlar |
| Sheath's color | standard is black,other color is also available |
| Connector | without or with 5 pin xlr,4 pin min xlr connector |
| Connector' color | silver or fully black |
The delivery time: | 10-100pcs | 3days |
| 100-500pcs | 7days |
| more than 500pcs | 10days |
Standard and fashion E-nail Coils as follows: Spring coil
ID16mm
Length 10.6/12.7/13.3mm;
Voltage : 24/110/120/220v;
Wattage:100/150/250w
With TC K/J
With Kevlar sleeve | Spring coil
ID20mm
Length 10.6/12.7m/13.3mm;
Voltage : 24/110/120/220v;
Wattage:100/150/250w
With TC K/J
With Kevlar sleeve | Flat coil type
ID9mm
OD 26mm
Voltage 120/220v
Wattage 100w/150w
With TC K/J
With Kevlar sleeve |
