LC-LC/LC-SC SM Fiber Optic Patch Cord
A smart and cost-effective solution for long distance transmission.
The 9/125 micron single mode fiber optic cable is suitable for enterprise network, telecom room, server farms, cloud storage networks, and any place fiber jumper cables are needed. It meets RoHS compliant, and cable is optically tested for insertion loss to ensure high quality.
| Connector | LC to LC | Jacket OD | 2.0mm |
| Fiber Type | 9/125μm | Fiber Count | Simplex |
| Polish Type | UPC to UPC | Jacket Material | PVC |
| Insertion loss | ≤0.3dB | Attenuation at 1310 nm | 0.36 dB/km |
| Return loss | ≥50dB | Attenuation at 1550 nm | 0.22 dB/km |
| Minimum Bend Radius | 30mm | Operating temperature | -40~75°C |
| Fiber Grade | G.652.D | Polarity | A(Tx) to B(Rx) |
Direct Connection with Simplex Fiber Patch Cable
For long distance and indoor applications, bidirectional data transfer depends on simplex SMF fiber patch cables in 1G/10G Ethernet connectivity environment, the below viewly shows the connection between hot-selling BIDI SFP transceivers and simplex LC-LC patch cables.
Product Highlights
1) The fiber optic cable has industry standard flammability rating OFNR (Riser) jacket and duplex fiber connector which meets EIA/TIA 604-2 for high speed cabling networks.
2) Quality zirconia ceramic ferrule ensures optimum IL and RL , giving you excellent performance.
3) Fiber type, cable jacket etc. in the bunch help clarify and recognize different cables.
4) 9/125um fiber core and 2.0mm cable diameter provide maximum protection.
Quality ControlAll products must go through five checks before manufacturing process
1.Material incoming inspection before production
2.Full check after every individual process finished
3.Full check after production half-done
4.Full check before packing
5.Spots check after production packed before shipping
Advantage1.15 years experience in manufacturing fiber optic products..
2.Availability of R & D with more than 10 engineers.
3.Available of design and making mold with special molding house.
4.High quality, attractive price and fast delivery(2-7days)
5.OEM, ODM customer designs are also welcomed
6.More than 200 workers
7.Excellent survice
Contact1.Our working time:8:30am~5:30pm
2.All the inquiries will be replied within 24hours, So please feel free to send us your inquiry.
3.When our trade manager is off line, please feel free to leave a message, and tell us the products you need, our model number, and your E-mail address, we will reply to you within 24hours too.
