Lm24 Cylinder Type Output Inductive Proximity Switch 2 Wires No+Nc Metal Waterproof Sensor
| Price: |
Negotiable/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
Product Description
Inductive proximity switch
Main features
1. Compact volume
2. High precision of repeated location
3. Diversified exterior structures
4. Good performance of anti-interference
5. Many output forms
6. High on-off frequency
7. Wide voltage range
8. Dust proof, vibration proof, water proof and oil proof
9. With short-circuit protection and inverted connecting protection
10. Long service life
Application
1. Various location detection of machinery process center
2. Arm location detection of robot
3. Inspection of the existing of milk inside the paper paxkage
4. Stopper detection of grinding machine
5. Bottle lid detection
6. Spacing detection
Switch type:
LM: Inductance type CM: Capacitance type SM: Hall type
AM: Safety explosion-proof type XM: HM: Reed type
Working voltage
30: 6-36V 310: 5-24VDC 320: 12-60VDC
20: 90-250VAC 210: 24-250VAC 220: 380VAC
40: 12-240VAC/24-240VAC 50: Special
Detection distance: 01: 1mm 05: 5mm 10: 10mm
Output form
N: NPN Three-wire DC NPN output
P: PNP Three-wire DC PNP output
L: Two-wire DC output
W: AC Three-wire output
J: Relay contact output
NP: NPN+PNP NPN+PNP double output
Output state
A: Normally open(NO)
B: Normally close(NC)
C: Normally open + Normally close (NO+NC)
MU: Mimic voltage
MI: Mimic current
Subsidiary functions
T: With aviation connector
Y: Water proof, oil proof
H: High temp resistance.
parameter
| DETECTION DISTANCE 8mm | |
| Flush | DC 10-30V | NPN | NO | LM24-3008NA |
| NC | LM24-3008NB |
| NO+NC | LM24-3008NC |
| PNP | NO | LM24-3008PA |
| NC | LM24-3008PB |
| NO+NC | LM24-3008PC |
| two wire system | NO | LM24-3008LA |
| NC | LM24-3008LB |
| AC 90-250V | SCR Control-lable silicon | NO | LM24-2008A |
| NC | LM24-2008B |
| NO+NC | LM24-2008C |
| Relay output | |
| | DETECTION DISTANCE 10mm |
| Non-Flush | DC 10-30V | NPN | NO | LM24-3010NA |
| NC | LM24-3010NB |
| NO+NC | LM24-3010NC |
| PNP | NO | LM24-3010PA |
| NC | LM24-3010PB |
| NO+NC | LM24-3010PC |
| two wire system | NO | LM24-3010LA |
| NC | LM24-3010LB |
| AC 90-250V | SCR Control-lable silicon | NO | LM24-2010A |
| NC | LM24-2010B |
| NO+NC | LM24-2010C |
| Relay output | |
| Controloutput | DC | 200mA |
| SCR/ Relay | 300mA |
| Output voltagc dropDC/AC | NPN/PNP< 3V, Two wire< 3.9V, AC< 10V |
| Consumption current | DC< 15mA, AC< 10mA |
| Standard detected object | 24*24*1(A3 iron) |
| Repeated precision | 0.05 |
| DC/AC | 200Hz/25Hz |
| Working environment temperature | -25~+70º C |
| Insulation resistance | 50MΩ |
| Shell material | Metal |
| Protection grade | IP67 |
| Altemative model at home and abroad | LJ24A3-10-
|
| Prod Model: |
LM24 |
| Detect Distance: |
50-800mm |
| Output Type: |
1 Switch Output E5 |
| Shell Material: |
Metal |
| Working Environment Temperature: |
-25c-75c |
