Rack Mount Power Distribution Unit 8-Way 0u Vertical IEC C13 PDU with 16A IEC60309 Plug

Name: Rack Mount Power Distribution Unit 8-Way 0u Vertical IEC C13 PDU with 16A IEC60309 Plug
Brand: all-electronics-online.com
SKU: 733051262
Availability: InStock
Rating: 4.4 (131 reviews)

Price:	Negotiable/Piece
Min Order:	20/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Feature

Vertical mounted industrial PDU socket, with leak-current protector
Aluminum-alloy shell,made from block burn PC,Guage:3G 14AWG+UL plug
According to customer request, we could add AC or DC display
Color: Black or silver
Children safty protect.
Braker protection, and fused.

Specifications

Rated current	16A Max
Rated load	4000W Max
Rated voltage	250V
Household voltage	230V
Number of sockets	3 to 48 ways
Size	19" 1U
Shell material	Uninflammable PC module, Aluminium alloy shell
Type of cable	3G4mm²2m
Type of plug	Industrial 16A plug; 32A for optional
Degree of protection against electric shock	IP20
Provision for earthing	With earting contact
Method of connecting the cable	Non-rewirable
Type of connections	Welded-solder
Degree of protection against electric shock	Normal protection
Existence of shutters	With shutters
Method of application-mounting	Portable type

Front view

Industrial plug

Circuit breaker

Cable gland

Silver tag

Packing information

Carton size	72x30x37cm
Product box size	70147 cm
Quantity in one carton	10 pcs
Metal enclosure
Gross weight for one carton	21kg
Net Weight for one carton	19kg
Plastic enclosure
Gross weight for one carton	19kg
Net Weight for one carton	17kg

=Shipment & Delivery =

Shipment	Note
Express	Door to door, very convenient, don't need to clearance or pick-up
By air	Airport to airport, you need to do the customs clearance and pick up the goods at your local airport
By sea	Port to port and you need to do the customs clearance and pick-up the goods at your local port

Webitelecomms take great commitments to photograph products indeed without any cheating and plagiarism.

FAQ

1)    What is your Payment term?
---T/T, L/C, Western Union could be accepted.

2)    What is your Trade term?
---EXW, FOB, CNF, CIF all are available

3)    What is the Loading Port?
--- Ningbo or Shanghai port.

4)    What is your MOQ?
---Webitelecomms fiber panel box MOQ is 50 pcs, different items will be different. We have indicated the MOQ for each item in the price list.

5)    What is your Product Warranty?
---As Europe market, we have CE RoHS and other international safety standard for our products.
---As other market,  international safety standard certificate is also be provided.

Prod Model:	WB-PDU-09-8IEC16A1P
Height:	0ru
Rated Voltage:	250VAC 50-60Hz
Rated Current:	16A
Materials:	Aluminum-Alloy Shell+ ABS
Input:	16A/32A Industril Plug
Output:	8 IEC320 Locking C13
Grounding:	Standard Grounding
Shell Material:	Aluminum Alloy
Application:	Residential/General-Purpose
Cable Length:	2 Meter
Color:	Black
IP Rating:	IP20
Certification:	ISO: 9001
Customized:	Customized
Condition:	New

WebiTelecomms, An energetic and dynamic company which specializes in INTEGRATED CABLING service, built in 2003. For these years, WebiTelecomms present her trustworthy and comprehensive products around the world.

Whether you are a small and medium enterprise or a large corporate customer, we understand that you require a high level of support at both pre-sales and post-sales side. At Webitelecomms, Everything will be shared to you.

Qualified design is given by engineers team with the latest feature.

Considerate quotation to be offered by sales team in-time as per your indeed need.

80, 000 sqm workshop field stands and looks for large challanges.

Trained labors and managements will be basic support.

So, WHAT YOU CAN GET from our team?

Creative and thoughtful idea

Honest and Responsible service

Flexible and technical response.

The point is: Trusted and affordable products

We never stop asking ourselves how we can make the customer experience better, and every day, we find an answer.

Choosing our services will not be the last good decision you make!
