Product Description
2 layers separate EM shielding FPC
Model:F10688
Type:EM shielding flexible pcb
Layers:2
Base material:1/2oz CU/0.5MIL ADH/0.5MIL PI(RA)
Coverlayer:0.6MIL ADH/0.5MIL PI
Dimensions:74.8mmx21mm
Surface treatment: ENIGAu:Au:0.03-0.09um,Ni:2-6um
EMI shielding:Electromagnetic shielding film x2
Meet the RoHS & WEEE lead-free requirement
Advantage:1. Over 10 years' manufacturing experience
2. Assembly provided
3. 100% quality tested before shipment
4. Certificate of UL, ISO9001, ISO14001 and ISO/TS16949.
5. Our Products meet the RoHS & WEEE lead-free requirement.
6. Small Order accepted
7. 3 weeks for massive production; 10 days for sample since material prepared
Urgent case or spread delivery schedule will be updated per negociation then
FPC Apply:
medical apparatus
automobiles
aerospace
industrial equipment
detecting instruments
smart-home controller
consumer electronics, etc
