Single Point Load Cell for Platform Scale (B749)

Name: Single Point Load Cell for Platform Scale (B749)
Brand: all-electronics-online.com
SKU: 829331035
Availability: InStock
Rating: 5 (90 reviews)

Price:	US $ 15-18/Piece
Min Order:	2/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	B749
Capacity:	60,100,150,200,250kg
Custom:	Size and Accuracy Could Be Customed
Pattern:	Single Point
Out-Wire:	5 Wires
Feature:	High Precision
Production Process:	Strain Gauge
Material:	Aluminum
IP Rating:	IP66

Product Description

1. Name:60,100,150,200,250kg single point Load Cell for platform scale
2. Material: Aluminum

3. Capacity: 60,100,150,200,250kg
4. Accuracy: C3
l Made of aluminum alloy.
l High accuracy, high side load tolerance
l Easy to install, IP65 protection
l Mainly used for electronic scales, electronic balance, price computing scales and industrial weighing systems

5. Datasheet

Number	Specifications	Technique
1	Capacity	60,100,150,200,250kg
2	Accuracy class	C3
3	Rated output	2.0±5%mV/V
4	Zero balance	±2%F.S.
5	Non-linearity	0.02%F.S.
6	Hysteresis	0.02%F.S.
7	Repeatability	0.02%F.S.
8	Creep(30min)	0.02%F.S.
9	Temp.effect on output	0.002%F.S./10ºC
10	Temp.effect on zero	0.003%F.S./10ºC
11	Input impedance	410±15Ω
12	Output impedance	350±5Ω
13	Insulation	≥5000MΩ/100VDC
14	Recommended excitation	5~12V
15	Maximum excitation	15V
16	Compensated temp range	-10~40ºC
17	Operation temp range	-20~60ºC
18	Safe overload	150%F.S.
19	Ultimate overload	200%F.S.
20	Cable size	Φ4×500mm
21	Weight approx.	0.25kg
22	Material	aluminum alloy
23	IP Class	IP66/IP67
24	Max.platform size	400mm×400mm

Advantages:

Made of aluminum alloy.

High accuracy, high side load tolerance

Easy to install, IP65 protection

Mainly used for electronic scales, electronic balance, price computing scales and industrial weighing systems

www.bransensor.com

What you could get from Brans?

Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.

Why choose Brans?

Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.

We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.

Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.

Who Brans cooperate with?

Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
