Three-Phase Induction Permanent Magnet Motor
| Price: |
US $ 200-150000/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P |
TYB Series explosion-proof permanent motor for mining Center height132~315) The efficiency index of TYB series accords to the first level standard of GB 30253-2013 "permanent magnet synchronous motor allowable values of energy efficiency and rate", the performance has reached an advanced level in the world.TYB series is based on Q/MT03-2013 "TYB series of mine explosion-proof three-phase permanent magnet synchronous motor" design, and fully enclosed with self-cooling fan structure, as well as air cooling, IP55 protection class, F-class insulation and S1 work system, sharing the same mounting dimensions with YB3 series motor. The explosion-proof sign is 'Ex d I Mb'.Products of TYB series are more efficient and have wider economical operation range with significant energy saving effect in 25% -120% load range relative to the same specifications of asynchronous motors. Under the rated load, the motor's temperature rise is in 30-50K.This serieshas awarded conformity certificate of protection issued by national explosion-proof electrical product quality supervision and inspection center,mining safety certification mark issued by National Mine Product Safety Mark Center and production licence issued by the State Bureau of Quality Technical Supervision(CSBTS).ENNENG TYB series motors are widely applied in non-working surface coal mining, to drive fans, pumps, belt machines and other machinery. Products powered by a three-phase 50 Hz 380 volt grid. Under nominated frequency and voltage it can be self-started. Also, based on your requirements, we can customize 660V and 1140Vmotor.
| Prod Model: |
TYB |
| Application: |
Industrial |
| Magnetic Structure: |
Permanent Magnet |
| Structure: |
Rotating Pole Type (',Armature Fixed) |
| Ventilation: |
Closed |
| Operating Speed: |
750r/Min |
| Operation Mode: |
Self-Starting |
| Number Of Poles: |
Eight-Pole |
| Certification: |
TUV |
| Brand: |
Enn |
ENNENG MOTOR FOCUS ON ENERGY SAVING PERMANENT MAGNETIC MOTOR R&D AND FABRICATION.
QUALITY IS OUR CULTURE.
Qingdao Enneng Motor Co., Ltd. (called "ENNENG") is a HI-TECH enterprise and its core competency is researching and fabrication of permanent magnetic motor(PM motor). The niche market is in China. Our PM motor has been successfully used in Chinese top leading enterprise in the field, such as Shengli Oil field, Chongqing Water Group, etc.
ENNENG is devoted to the research and development of various low speed permanent magnetic motor with high torque, special small permanent magnet servo motor and super-high speed permanent magnetic motor. With advanced production idea, strong technical strength, complete process equipment and advanced test and inspection equipment, our company is one of the leading permanent magnetic motor manufacturers. Our product can be used in port, ship, coal, water conservancy, mine, petro and power industry. We are praised and recognized by the customer for several research and development projects which wins high reputation and long-term cooperation with the customer.
ENNENG is continuously boost independent innovation, and cooperate with many colleges like China University of Mining and Technology, China Ocean University, Shandong University of Science and Technology, Xi 'an university of Science and Technology, China University of Petroleum, Beijing University of Aeronautics and Astronautics etc. We have a team with years of permanent magnetic motor experiences in the industry like mine, port, water conservancy, building materials, petro, chemical and space etc. And they have abundant professional technique and management who is familiar with motor design and production process supplying stable quality and professional service permanent magnetic motor system.
ENNENG headquarter is located in Qingdao, with factory in Dalian. 90% of the fabrication and test equipment are imported from Germany.
FOR ENERGY SAVING, USE ENNENG PM MOTOR.
