1.25g 850nm LC 550m SFP Optical Module Transceiver Dual Fiber
| Price: |
US $ 1-20/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
SFP transceiver |
| Item Name: |
SFP Module |
| Working Rate: |
1.25gbs/S |
| Mode Type: |
Mutil Mode |
| Wavelength: |
850nm |
| Fiber Type: |
Dual Fiber |
| Reach Distance: |
550m |
| Compatible Brands: |
Cisco,HP,H3c,etc |
| Customized: |
Available |
| Usage: |
Laptop |
| Type: |
Wired |
| Support Network: |
Ethernet |
| Information Content: |
Data |
| Certification: |
GS |
| Condition: |
New |
Product Description
1.25g 850nm LC 550m SFP Optical Module Transceiver Dual FiberSFP Optical module Transceivers are hot-swappable, compact media connectors that provide instant fiber connectivity for your networking gear. They are a cost effective way to connect a single network device to a wide variety of fiber cable distances and types.
Description
1.The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 550m transmission distance with MMF.
2.The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety
requirements.
3.The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further
information, please refer to SFP MSA.
Features
1.Data-rate of 1.25Gbps operation
2.850nm VCSEL laser and PIN photodetector
3.Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
4.Digital Diagnostic Monitoring: Internal Calibration or External Calibration
5.550m transmission with 50/125µm MMF
6.270m transmission with 62.5/125µm MMF
7.Compatible with SONET OC-24-LR-1
8.Compatible with RoHS
9.+3.3V single power supply
10.Operating case temperature range of 0°C to +70°C (Standard) or -40°C to +85°C (Industrial)
Spec| Optical Fiber Module |
| Standards and Protocols | IEEE 802.3z, CSMA/CD, TCP/IP |
| Wave Length | TX: 1550nm / RX: 1310nm |
| Power Supply | 3.3V |
| Cable | Single-mode Fiber |
| Fiber Type | 9/125 um Single-mode |
| Max. Cable Length | 20KM |
| Data Rate | 1.25Gbps |
| Port Type | LC or SC |
| Safety & Emission | FCC, CE,RoHS |
| Temperature | Operating Temperature: 0°C~70°C (32 ° F~158 ° F )
Storage Temperature: -40°C~80°C (-40 ° F ~176 ° F ) |
| Humidity | Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
What we can do for you??1.High efficiency,with more than 3000 square meters size & 150+ professional workers can finish your order within a week
2.Quality assurance,we are a factory strictly operating ISO 9001:2008 quality control system,twice check before delivery
3.Competitve price.As a factory,costs are controllable
4.Flexible payment term.T/T,L/C,paypal is availble
5.Professional,Our workers are at least 3 years experience in fiber optic fields,besides,we cooperated with Electroson,Telefonica,etc
6.Complete product range, products cover fiber optic cable,Fiber optic adapter,attenuators,full total FTTH solution.
Any doubt about SFP Optical Module/Transceiver,please leave me an inquiry or contact me directly.
Takfly Communications Co., Ltd. is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipments.
The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry. All the products acquired the approval of the Network Access License for Telecommunication Equipment Ministry of Information Industry, PRC, ISO9001, UL and CE standard, which ensure the reliability and make them sold very well not only in the domestic market but also the overseas market.
TAKFLY was establish in 2000, grow up rapidly. Now it has workshop area about 3000 square meters, more than 200 workers, the production capacity of fiber optic connectors is about 600, 000PCS per month. It controls the quality constantly and strictly in order to give the best products to the users. The outstanding features and advantage are the high technology, professional and excellent sales team, efficient and sound management, competitive price, wide and superior channels, as well as high-quality and flexible service.
Many international exhibitions upgraded "TAKFLY" as the well-known brand in the world. To be the super leader of the optical communications scopes in China is the goal of TAKFLY. In the next five years, TAKFLY will keep the strategic pattern of development ---"based in South China, penetrate into whole country, extend over the world". It will bring the fiber optic industry into a brilliant future. TAKFLY--- Your Honest Team, will be always ready for you.
